Multihull pontoon boat A'Lure 19F

opencenter consolefishing

Overview
The 19F is designed for comfortable fishing with an L-style bow seat and three strategically positioned fishing chairs. A fiberglass livewell forward of the console provides fish storage. Suited for smaller lakes and small fishing groups or charters.

Standard Equipment

• Two U-shaped pontoon logs with 0.100 in gauge walls and nose cones
• Landau deck system
• Rod holders and cup holders
• Rotationally molded seat frames with water management system
• 7 ft color-coordinated Bimini top
• 12 Volt trolling motor wiring harness
• Marine-grade upholstery vinyls with protective finish
• 2 in aluminum extruded floor joists on 16 in centers
• Fold-down captain's helm chair
• Three fold-down fishing seats
• Two removable rod holders
• 12 Volt power outlet at console
• 3/4 spray shield
• Fiberglass aerated livewell
• Standard wheelchair-accessible bow gate
• Woven vinyl flooring
• Gate floor stops
• 4 stainless steel cleats
• Bow and stern stainless trailer tie down U-bolts
• Concealed battery storage
• Stainless steel rear boarding ladder with four steps
• 27 gallon direct fill fuel tank built into motor well
• Gauge package (tach, fuel, and speedometer with GPS)
• Fiberglass console with gauges and windshield
• Bluave® Bluetooth-ready AM/FM marine stereo system

Exterior Color Options

• Merlot
• Deep Blue
• Pearl
• Matte Black
• Sage Green
• Mocha
• Charcoal
• Midnight Black
• Metallic Sand

Top Panel Options

• Charcoal
• Deep Blue
• Matte Black
• Merlot
• Metallic Sand
• Pearl

Interior Vinyl Options

• Grey
• White
• Taupe
• Cognac

Optional Equipment
Performance

• Tri-log package (includes 3/4 spray shield, 32 gallon gas tank)
• Full spray shield
• 24 Volt trolling motor wiring harness (6 gauge wire)
• Dual battery shut off switch
• 25 in transom
• Full keel for dual and tri-log configurations
• Tilt steering
• Hydraulic steering / SeaStar
• Fish finder – Lowrance Eagle 5
• Lifting strakes (tri-logs)

Seating & Furniture

• Exchange helm fishing seat for Island Breeze captain's chair
• Add fishing chair
• Add livewell – fiberglass
• Add complete kidney-shaped table – Devil Wood (Tan) or Steel Blue (Grey)
• Add complete oval table – Devil Wood (Tan) or Steel Blue (Grey)
• Add extra table base
• Add adjustable height pedestal for captain exchange

Style & Appearance

• Docking lights
• Chrome light housing with navigation and docking lighting
• Smoked chrome light housing
• LED under-seat lighting
• Exchange standard cleats for fold-down cleats (2 pair)
• Trolling motor gate
• Top panel graphic
• Flooring upgrades

Addons & Extras

• Add mooring cover
• Add ski tow – walk thru
• Add tetra pad (tube storage over ski tow)
• Add portable rod holder insert(s) (no base)
• Add complete rod holder
• Add portable cup holder(s)
• Wireless pocket charger

Specifications

• BASIC
  Options: -
  Overall length: 20 feet, 10 inches (6.35 m)
  Deck length: 18 feet, 10 inches (5.74 m)
  Beam: 8.5 feet (2.59 m)
  Log number: 2
  Log size: 21 x 25 in (53.3 x 63.5 cm)
  Log gauge: 0.100 in (2.54 mm)
  Approx. weight: 1560 lbs (≈708 kg)
  Max passengers: 7
  Max capacity: 1593 lbs (≈723 kg)
  Max horsepower: 75 HP (≈56 kW)
• TRI-LOG
  Options: Tri-Log
  Overall length: 20 feet, 10 inches (6.35 m)
  Deck length: 18 feet, 10 inches (5.74 m)
  Beam: 8.5 feet (2.59 m)
  Log number: 3
  Log size: 21 x 25 in (53.3 x 63.5 cm)
  Log gauge: 0.100 in (2.54 mm)
  Approx. weight: 1669 lbs (≈757 kg)
  Max passengers: 7
  Max capacity: 2034 lbs (≈923 kg)
  Max horsepower: 90 HP (≈67 kW)
