Ship heater CNF（Z）-15~35

Product Overview
The marine steam heating fan is an air heating device that uses steam as the heating medium and air circulation for heating. Its working principle involves blowing air continuously onto the heat exchanger with its axial fan, allowing cold air to contact the high-temperature heater fins and heat pipes, thus heating the air. The heated air is expelled through the louvers, continuously drawing in cold air from the motor's tail end and expelling heated air, thereby increasing the indoor air temperature to achieve warmth.

• Product Features:

• Model Explanation: "C": Marine; "NF": Heating Fan; "Z": Steam Heating; "15~35": Heat Output (kW)
• The heating fan mainly consists of a casing, marine motor, axial fan, heat exchanger, and louvers.

• Product Functions:

• The marine steam heating fan is primarily used when the ship is docked, and the ambient temperature is near zero, to ensure the required cabin temperature for quick equipment startup and ship readiness. It is an essential device for ships and can also be used for crew heating in other cabins to supplement insufficient air conditioning heat.

• Product Advantages:

• The heating fan is lightweight, flexible, and sturdy, suitable for wall-mounted or floor-mounted installation. It is compact, lightweight, low-noise, corrosion-resistant, and highly resistant to sway, vibration, and impact.

Basic Parameters
● Air Volume: 1000~3500m³/h
● Heat Output: 15210~35400 kcal/h
● Power Supply: Standard AC 3PH 380V/50Hz, AC 3PH 440V/60Hz, with options for other power supplies: AC 3PH 415V/50Hz, AC 3PH 460V/60Hz, AC 3PH 480V/60Hz, AC 3PH 690V/60Hz.
● Casing: Welded steel plate, available in ordinary steel or various stainless steel plates as per user requirements.
● Impeller: Made of LF3 rust-proof aluminum, pressed aluminum plate with inclined blades.
● Heat Exchanger: Copper tube with copper fins, mechanically wound on the heat pipe for extensive and tight contact.
● Louvers: Stamped steel plate, adjustable blades for regulating air volume and direction.
● Marine Motor: Features excellent moisture, mildew, and salt spray resistance, stable operation, and low noise. The motor windings and metal parts are specially impregnated and treated for tropical climates, enhancing moisture, mildew, and salt spray resistance. The motor housing has axial cooling ribs for improved cooling. Space heaters can be added as required.
● Marine motors can be selected from domestic brands like Hengli, Jiangsu Dazhong, Yuandong, or imported brands like ABB, Siemens, and Baiwei.

Application Scenarios
Widely used in various types of passenger ships, cargo ships, naval vessels, and offshore oil platforms.

Product Characteristics/Specifications

• Model: CNF(Z)-15~35
• Air Volume: 1000~3500m³/h
• Heat Output: 15210~35400 kcal/h
• Power Supply: AC 3PH 380V/50Hz, AC 3PH 440V/60Hz (other options available)
• Casing Material: Steel/Stainless Steel
• Impeller Material: LF3 Rust-proof Aluminum
• Heat Exchanger Material: Copper Tube with Copper Fins
• Louver Material: Steel Plate
• Installation Method: Wall-mounted or Floor-mounted
• Applicable Scenarios: Passenger Ships, Cargo Ships, Naval Vessels, Offshore Oil Platforms
