Yard No: 088
Designer: Revolution Design Pty Ltd
Builder: Incat Tasmania Pty Ltd
Class Society: DNV/GL
Certification: DNV +1A1 HSLC R1 Car Ferry “B” EO
Length overall: 109.4 m
Length waterline: 103.2 m
Beam overall: 30.50 m
Beam of Hulls: 5.80 m
Speed: 39 knots at 600 DWT
Deadweight: 1000 tonnes.
Passenger Capacity: 1000 persons (including crew).
Passenger Deck: Located on one level, Tier 3, is divided into
Forward Tier 3 Business Class Lounge
Midships Tier 3 Economy Class Lounge,
Kiosk, Café and Children’s area.
Aft Tier 3 TV rooms and quiet lounge.
Vehicle Capacity: 411 cars (610 truck lane metres at 3.1m
wide and 4.6m clear height) plus 227 cars
at 4.5m length x 2.3m wide and 2.1m high.
Axle load: Tier 1 - 13 tonne (single axle dual wheel)
between transom and frame 70, CL to
4800 and between Transom and frame 60
outboard of 4800. 2.0 tonnes (single axle
dual wheel) fwd of frame 60 (outboard of
4800 only) and fwd of frame 70 elsewhere.
Axle load: Tier 2 - 2.0 tonne (single axle).
