Yard No: 064
Designer: Revolution Design Pty Ltd.
Builder: Incat Tasmania Pty Ltd.
Class Society: Det Norske Veritas
Certification: DNV 1A1 HSLC R1 Car Ferry “B” EO
Length overall: 112.60 m
Length waterline: 105.60 m
Beam moulded: 30.50 m
Beam of Hulls: 5.80 m
Speed: approx 40 knots at 600 DWT
Note - All speeds quoted at 100% MCR 4 x 9000 kW @
1000 rpm without deployment of T-foil, with clean
underwater parts and in water depths of 10 metres to 50
Max Deadweight - approx 880 tonnes or 1380 at reduced
Passenger Capacity - 800 persons (including crew)
Passenger Deck - located on two levels, the Passenger
Deck is divided into four lounges:
Forward Tier 3 Economy Class Lounge
Midship Tier 3 Entrance Lounge.
Aft Tier 3 Business Class Lounge.
Tier 4 Executive Class Lounge.
Vehicle Capacity - 450 truck lane metres at 3.1m wide and
4.35m clear height plus 193 cars at 4.5m length x 2.3m
wide or 355 cars only.
