Ro-Pax car ferry BONANZA EXPRESS

high-speedcatamaran

General Particulars Yard No: 051 Designer: Incat Tasmania Pty Ltd. Builder: Incat Tasmania Pty Ltd. Class Society: Det Norske Veritas Certification: DNV 1A1 HSLC R1 Car Ferry “B” EO Length overall: 95.47m Length waterline: 86.00m Beam overall: 26.60m Beam of Hulls: 4.50m Draft: 4.03m Speed: 38 knots at 686 tonnes deadweight 47 knots at lightship Note - All speeds quoted at the time of delivery at 100% MCR 4 x 7080 kW @ 1030 rpm without deployment of T-foil, with clean underwater parts and in water depths of 10 metres to 50 metres. Capacities Max Deadweight - 802 tonnes Passenger Capacity - 717 passengers + crew Passenger Deck - located on two levels, the Passenger Deck is divided into four lounges: - Tier 2 Aft Lounge with seating areas, Male/Female Toilets, Disability Toilet/Mothers Room, Children’s Play Area and external Passenger Deck. - Tier 2 Midship Lounge with seating areas and Bar. - Tier 2 Forward Lounge with seating areas, Kiosk, Food Preparation Area and Pursers Office. - Tier 3 Upper Lounge with seating areas, Bar, Male/Female Toilets, Lower Wheelhouse, Crew Mess and external Passenger Deck. Vehicle Capacity - 330 truck lane metres at 3.1m wide x 4.0m/4.35m clear height plus 80 cars at 4.5m length x 2.3m wide or 230 cars only using optional mezzanine decks.
