Power supply with battery MPS4

low-voltageDC

Description
Four independent adjustable 12V DC outputs in a compact metal enclosure with external battery input for UPS function. Ideal for installations requiring separated regulated outputs and per-channel protection.

Features

• PFC circuits
• Overvoltage protection
• Short-circuit protection
• Fuse per channel
• Adjustable output voltage 11–15 V DC
• Status LED per output
• External battery connection for UPS function
• Metal enclosure with lock
• Compact dimensions: 21 x 15 x 4 cm

Technical specifications

• Article code: MPS4
• Channels: 4
• Power supply type: Separate, adjustable outputs
• Output voltage: adjustable 11–15 V DC
• Protections: PFC, overvoltage, short-circuit
• Fuse: one per channel
• Indicators: status LED per output
• UPS function: external battery connection
• Enclosure: metal with lock
• Dimensions: 21 x 15 x 4 cm
