Axial fan-extractor Small

axial fan-extractor
axial fan-extractor
Add to favorites
Compare this product


Characteristics

Type
axial

Description

The 8 and 11 Inch AC Axial Fans are speed controllable using the WC 15 and WC 25 Adjustable Manual AC Fan Controls. 8 Inch Fan- 115 Volt AC – Part No. 500-208281/1 11 Inch Fan- 115 Volt AC – Part No. 500-211115 8 Inch Fan- 230 Volt AC – Part No. 500-208281/2 11 Inch Fan- 230 Volt AC – Part No. 500-211230 11 Inch (279.4 mm) Axial Fan’s with flow rates to 1100 CFM (1869 m3/h) Application Ideally suited for small vessel engine rooms and OEM applications where compact ventilation systems are required. These fans provide over four times the air volume of small AC centrifugal marine blowers with a substantial weight savings. Unbelievably quiet when running, these fans will provide thousands of hours of continuous service. Design & Construction The 8″ and 11″ Axial Ventilation Fans are specifically designed and built for the rigors of the marine environment. With a flanged housing of cast aluminum, this lightweight unit provides a compact fan with excellent corrosion resistance. Extended wiring leads from the motor to a terminal strip provide for simple quick installation. Motor 50/60 HZ High efficiency single phase direct drive motor provides extremely quiet continuous duty service, yet draw only 80 WATTS. Motors are totally enclosed (TEAO) double shielded ball bearing type. Available in both 115 VAC and 230 VAC, these motors are designed for worldwide applications. Fan Hubs & Blades A corrosion resistant hub is secured directly to the motor shaft using multiple locking methods for enhanced safety and reliability. Fan blades are finished with black powder coated paint for corrosion resistance.

Catalogs
