Standard Capacities and Features
Capacity (weight) 120,000 lbs
Standard Dimensions: (can be adjusted to meet requirements)
Height Overall 23' 3"
Clear Height 20'
Width Overall 25'
Clear Width (inside) 20'
Wheel Base 21'
Open end HSS frame, with forward mounted crossbeam & equalizing joint to relieve stress
Fuel and hydraulic tanks are integral in main frame construction
Power Unit: 85 HP Perkins Diesel Tier 3
Drive System: Full hydrostatic drive with dynamic braking (multi wet-disk parking brake)
Travel Speed: Variable from 0 to 100' per minute
Grade Capability: Maximum 5% incline
Lift Speed: From 1' to 20' per minute
Two speed Braden hydraulic winches
Steering: 90 degree steering capability with powered slew bearings
Pilot operated safety lock-valves on each lift point
Gondola style with controls for all functions, including full engine instrumentation
Four point lift functions can be simultaneously or independently operated
Operator's screen has built in hydraulic test gauges and service tools
Digital load gauges
Slings: 2 - 12" center-disconnect slings with hydraulic fore / aft adjustment
Tires: 54" x 16" 28 ply lug tread industrial tires
Forward and backwards motion alarm
Stainless steel hydraulic tubing and hardware
Complete sandblast to white metal, 1 coat zinc primer, 1 coat epoxy high build primer
Polyurethane paint - 2 coats of Conolift Red PPG commercial performance paint
2 year warranty on frame / 1 year on hydraulic components / or 2000 hrs whichever comes first
