Standard Capacities and Features
Capacity (weight) 160,000 lbs
Standard Dimensions: (can be adjusted to meet requirements)
Height Overall 26' 6"
Clear Height 24'
Width Overall 27' 6"
Clear Width (inside) 21'
Wheel Base 23' 6"
Cable Drop (into well) 12'
Open end HSS frame, with forward mounted crossbeam & equalizing joint to relieve stress
Fuel and hydraulic tanks are integral in main frame construction
Power Unit: 100 HP CAT Diesel
Drive System: Full hydrostatic drive with dynamic braking (multi wet-disk parking brake)
Travel Speed: Variable from 0 to 100' per minute
Grade Capability: Maximum 5% incline
Lift Speed: From 1' to 20' per minute
Steering: 90 degree steering capability
Pilot operated safety lock-valves on each lift point
Gondola style with controls for all functions, including full engine instrumentation
Four point lift functions can be simultaneously or independently operated
Slings: 4 - 12" center-disconnect slings with hydraulic fore / aft adjustment
Tires: 54" x 16" 28 ply lug tread industrial tires
Forward and backwards motion alarm
Digital load guages (lbs or kgs)
Complete sandblast to white metal, 1 coat zinc primer, 1 coat epoxy high build primer
Polyurethane paint - 2 coats of Conolift Red PPG commercial performance paint
2 year warranty on frame / 1 year on hydraulic components / or 2000 hrs whichever comes first
Custom colour choice - 189 colors to choose from
Radio Remote Control - all functions including drive and steering
Cold weather package - includes engine and hydraulic heaters
Delivery, set-up, and operator training
