- AQUILA POWER CATAMARANS
Catamaran 50cruising4-cabin5-cabin
Add to favorites
Compare this product
Characteristics
- Number of hulls
- catamaran
- Intended use
- cruising
- Number of cabins
- 4-cabin, 5-cabin, 6-cabin
- Maximum berth number
- 14 berths
- Deck layout
- flybridge
- Rigging
- with bowsprit
- Other characteristics
- sail-drive
- Overall length
14.97 m
(49'01" )- Width
7.86 m
(25'09" )- Draft
1.45 m
(4'09" )- Displacement
19.2 t, 24 t
(21.16 us ton, 26.46 us ton)- Sail area
156 m²
(1,679 ft²)- Motor power
100 ch
(100 hp)- Fuel capacity
865 l
(229 gal)- Fresh water capacity
880 l
(232 gal)
Description
Overview
Aquila's all-new 50 sail catamaran is designed to maximize usable space, onboard functionality and long-range comfort. Key naval and deck design choices include a fixed bow for day-boarding and entertaining, large panoramic windows for natural light and visibility, and bridge-to-bow access from the flybridge to the foredeck cockpit. The layout is configurable in 4, 5 or 6 cabin variants, each with private entrances. Available with diesel propulsion or a Hybrid Ocean Drive™ option. Expected delivery: February 2026.
Key features
Specifications (summary)
Length Overall (LOA): 14.97 m / 49'1"
Beam: 7.86 m / 25'9"
Height above waterline: 5.55 m / 18'3"
Mast height above waterline (light load): 25.15 m / 82'6"
Draft: 1.45 m / 4'8" (varies with load)
Maximum passengers: 30
Cabins: 4 / 5 / 6
Heads with showers: 4 / 5 / 6
Utility rooms: 1
Mainsail (standard pin top): 90 m² / 968.8 ft²
Furling Genoa: 66.0 m² / 710.4 ft²
Total upwind sail area: 156 m² / 1,679.2 ft²
Hybrid Ocean Drive: 2 × 50 kW Deep Blue Torqeedo inboard motors
Diesel: 2 × 50 HP saildrives
CE Certification: A: 12, B: 12, C: 20, D: 30
Technical specifications
Aquila's all-new 50 sail catamaran is designed to maximize usable space, onboard functionality and long-range comfort. Key naval and deck design choices include a fixed bow for day-boarding and entertaining, large panoramic windows for natural light and visibility, and bridge-to-bow access from the flybridge to the foredeck cockpit. The layout is configurable in 4, 5 or 6 cabin variants, each with private entrances. Available with diesel propulsion or a Hybrid Ocean Drive™ option. Expected delivery: February 2026.
Key features
- Fixed bow area optimised for social and relaxation spaces
- Choice of diesel saildrives or whisper-quiet Hybrid Ocean Drive™ inboards
- Panoramic windows providing extensive natural light and sightlines
- Spacious salons and galleys arranged as a functional command centre
- Bridge-to-bow access enabling quick movement between flybridge and foredeck cockpit
- Configurable 4, 5 or 6 cabin layouts with private entrances for owners and guests
Specifications (summary)
Length Overall (LOA): 14.97 m / 49'1"
Beam: 7.86 m / 25'9"
Height above waterline: 5.55 m / 18'3"
Mast height above waterline (light load): 25.15 m / 82'6"
Draft: 1.45 m / 4'8" (varies with load)
Maximum passengers: 30
Cabins: 4 / 5 / 6
Heads with showers: 4 / 5 / 6
Utility rooms: 1
Mainsail (standard pin top): 90 m² / 968.8 ft²
Furling Genoa: 66.0 m² / 710.4 ft²
Total upwind sail area: 156 m² / 1,679.2 ft²
Hybrid Ocean Drive: 2 × 50 kW Deep Blue Torqeedo inboard motors
Diesel: 2 × 50 HP saildrives
CE Certification: A: 12, B: 12, C: 20, D: 30
Technical specifications
- Model: 50 Sail
- Length Overall (LOA): 14.97 m (49'1")
- Beam: 7.86 m (25'9")
- Height above waterline: 5.55 m (18'3")
- Mast height above waterline (light load): 25.15 m (82'6")
- Draft: 1.45 m (4'8") — varies with load
- Maximum passengers: 30
- Cabin configurations: 4 / 5 / 6
- Heads with showers: 4 / 5 / 6
- Utility rooms: 1
- Mainsail (standard pin top): 90 m² (968.8 ft²)
- Furling Genoa: 66.0 m² (710.4 ft²)
- Total upwind sail area: 156 m² (1,679.2 ft²)
- Hybrid propulsion: 2 × 50 kW Deep Blue Torqeedo inboard motors
- Diesel propulsion: 2 × 50 HP saildrives
- CE certification categories: A:12, B:12, C:20, D:30
