Courtesy wall light 00483 series

for exterior lightingoutdoorfor boat

Product overview:
The Series 00483 LED courtesy light is a flush-mount marine fixture designed for deck, stair riser and walkway illumination. Diameter Ø203 × 25mm provides wide-area coverage while maintaining a low profile suitable for onboard installations. The unit features a PC housing with a polished S.S.304 stainless steel trim ring and an IP67 rating for reliable operation in marine environments.

Construction and performance:

• PC housing with polished S.S.304 stainless steel trim ring for corrosion resistance
• IP67 ingress protection for splash and temporary immersion resistance
• 15 RGBW LEDs with built-in PCB driver for stable operation
• Rated for 12VDC operation at 0.5W per cycle for energy-efficient lighting

Optical options and outputs:

• 00483-SSBU: Blue — 23 LM
• 00483-SSWH: Daylight White — 176 LM
• 00483-SSRGBW: RGBW — White: 107 LM / Green: 67 LM / Blue: 17 LM / Red: 17 LM

Ordering information:

• Model codes: 00483-SSBU, 00483-SSWH, 00483-SSRGBW
• Suitable for new builds and refit projects on recreational and commercial vessels

Packing & logistics:
240 units per carton (240/CTN)

Technical specifications:

• Model series: 00483 series
• Mount: Flush mount, Ø203 × 25mm
• Operating voltage: 12VDC
• LEDs: 15 RGBW LEDs
• Power consumption: 0.5W per cycle (built-in PCB driver)
• Materials: PC housing with polished S.S.304 stainless steel trim ring
• Ingress protection: IP67
• Color/variants & luminous output: 00483-SSBU (Blue: 23 LM); 00483-SSWH (Daylight White: 176 LM); 00483-SSRGBW (RGBW — White: 107 LM / Green: 67 LM / Blue: 17 LM / Red: 17 LM)
• Packing quantity: 240 units per carton
