Spraying gun 26832

for shipyards

Overview
Lightweight and easy to use, the 3M™ Performance Spray Gun was built for the modern painter. Capable of spraying a wide range of coatings from either a pressure-fed source or an attached gravity cup. Impact-resistant composite body makes it one of the lightest spray guns available while remaining durable for industrial and automotive conditions. The PN 26832 kit includes a 3M™ Performance Spray Gun and an air control valve. The gun was ergonomically optimized to enhance comfort for all-day spraying.

Key features

• Lightweight, impact-resistant body made from advanced composite material
• Quickly converts between pressure-fed systems and gravity-fed 3M™ PPS™ Series 2.0 Spray Cup System
• Easy-change, replaceable nozzles available in a wide range (atomizing heads from 1.1 to 2.0)
• Designed for comfort with an intuitive, simple design
• Fewer parts to maintain or rebuild; paint does not pass through the gun body, simplifying cleanup

Typical properties
Air Consumption (Imperial): 13 cfm
Air Consumption (Metric): 370.5 L/min
Application: Primer, Paint Application, Coating spraying, Clear Coat, Coating Application, Painting, Spraying
Brands: 3M™
Case Quantity: 4.0 per Case
Smallest Saleable Unit: Kit

Resources
Technical data sheet available (PDF).

Technical specifications

• Part Number: 26832
• 3M ID: 7100228104
• UPC: 00051131268326
• Air consumption: 13 cfm / 370.5 L/min
• Suitable applications: primers, paints, clear coats and general coating spraying
• Compatibility: converts between pressure-fed systems and 3M™ PPS™ Series 2.0 Spray Cup System
• Nozzle/atomizing head sizes: ranges from 1.1 to 2.0 (quick-change, replaceable)
• Case quantity: 4 per case
• Smallest saleable unit: kit
