Ø SHEAVE: 60mm MAX Ø LINE: 18mm MAX WORKING LOAD: 2200Kg BREAKING LOAD: 4400Kg SCREW: 3xM6 HEIGHT: 72mm WEIGHT: 340g
Specifications Weight: 122.00 g Safe working load: 700 kg Breaking load: 1400 kg Breaking load upper: 7.00 kN System: 40 Fasteners: 2xM6
Weight: 439.00 g Safe working Load: 700 kg Breaking Load: 1400 kg Breaking load upper: 7.00 kN MaxLineSize: 14 mm System: 40 Fasteners: 6xM6
Our aluminum high load sheave boxes feature a low friction plain bearing for high working load and ball bearing for side loads. An excellent weight to working load ratio. Contact us if you do not find the right model for your application. ...
KARVER SYSTEMS
Weight - 0.231 kg Boat size - 30 to 40 ft Workload - 1,50 T Breaking load - 3,00 T
KARVER SYSTEMS
Weight - 0.547 kg Boat size - 30 to 60 ft Workload - 3,00 T Breaking load - 6,00 T
KARVER SYSTEMS
All organisers have space to pass two lines between each sheave Flush fixings Synchro Organiser ■ Bushed sheaves with side thrust ball bearings ■ Wide rope entry
60mm Bushed Sheaves Organisers ■ Tough interchangeable acetal sheaves ■ Black anodised body with black sheaves ■ Stackable
60mm Bushed Sheaves Organisers ■ Tough interchangeable acetal sheaves ■ Black anodised body with black sheaves ■ Stackable
Deck organizers lead halyards and control lines aft, allowing crew to sail from the security of the cockpit. Deck organizers lead a large number of lines through a small space.
Harken
... Specifications Product Specifications Type of Block - Deck Organisers B.L. (kg) - 1000 M.W.L. (kg) - 500 Max. Rope diameter (mm) - 12 Weight (g) - 185 Fastener Ø (mm) - 6 Qty. Fasteners - 6 Deck ...
... sheaves Fibre-reinforced construction Stainless steel wear strip prevents local rope damage Curves to follow the shape of the deck Double stack with BE10/2 or /3 (see BE10 multiple range) for lowest cost stacked line solution
Spinlock
... aluminum are especially developed for smooth and safe line handling on big boats with high loads. Each sheave is bolted through deck and has a durable Kevlar bearing which together with the strong design gives a very ...
RUTGERSON
... of 24mm. Screws are not included, and shall be chosen depending on deck thickness. The optional mounting plate in aluminum is made for the ROC Organiser assortment. Fitted under the deck, it spreads ...
RUTGERSON
... 24mm. Screws are not included, and shall be chosen depending on deck thickness. The optional mounting plate in aluminum is made for the ROC Organiser assortment. Fitted under the deck, it spreads ...
RUTGERSON
3 Series Triple Aluminum deck organizer. Stainless Steel base and anodized aluminum top strap provide a high strength base. Delrin(tm) sheaves ensure smooth operation and high strength. Sheave Dia. 1-7/16" ...
Schaefer
Length (L) - 120 mm Width (W) - 30 mm Height (H) - 39 mm No. sheaves - 4 Ø sheave (D) - 28 mm Weight - 0,22 kg Ø max line - 14 mm B - 30 mm C - 14 mm SWL - 400 kg Fixing screws - 4 x 6 mm
Antal
Deck organizers with Delrin captive ball bearings sheaves Rope diameter (from 4 to 12 mm) Can be stacked to optimized space Suit perfectly with the esthetics of modern boats Available with 4 sheaves Spacing: ...
Fixing screws are independent to the closing ones. This gives a better finish to the boat’s interior, with the head of the screw coming through the head lining, rather than bolt, washer and nut. This construction also aids servicing ...
28mm 3 sheave deck organiser for 8mm rope, 6mm fixing hole centres 33mm
Designed for use when leading control lines halyards across the coach roof and back to the cockpit. This range features aluminium construction with 'Spectro' grey annodised finish. Sheaves are from moulded acetal with hollow rivets to ...
Barton Marine
Distributor Block Art. 7325 subject to errors and changes
Our range of aluminium lead blocks are available in both natural and black anodised aluminium, with or without ball bearings, small sized as well as medium and heavy duty foot blocks. Sheave sizes from 32x12 mm up to 49x18 mm.
OH MARINE EQUIPMENT
... Multi-purpose textile chainplate and FrD® friction ring perfect for organizing sheets, lines, etc. - Easily installed anywhere on the deck, mast or boom... + DATA SHEET - Padeye SX® in technical PA filled with ...
LOOP® ORGANIZER KOHLHOFF LOOP® Very flexible, easy and strong. These three points make the KOHLHOFF LOOP® Deck Organizer so unique. There is no longer a problem to add a new halyard ...
Our halyard organisers and deflectors are built to requirement in any numbers or configuration. KEY DESIGN FEATURES Size: Customised to suit. Options: Sheave size. Aluminium, titanium, and carbon plates.
... accessories. » Suit for 8m small boat Use for: Halyards Spinnaker pôles Control lines Reef lines Can be fixed on deck with screw 316 SS axle sleeve
Blue Shark Marine Ltd.
For roping: up to 12mm Roller: 3 Length: 210mm Width: 40mm Height: 25mm Hole clearance: 57 mm Weight: 260g Colour: black Fixing screws: Countersunk M6 Note: Aluminum rollers with ball bearing
Anodised light alloy frame, pins and bushes in AISI 316 stainless steel, delrin sheaves, supplied complete with fixing screws and nuts. Code 198.165 For lines: Ø max 14 mm Black sheave Ø 40×18 mm Length: 230 mm Width: 40 mm
A deck organizer is a fitting composed of one or several vertical-axis sheaves encased in a horizontal rack bolted to the deck. They lead halyards, downhauls, reef lines and other rigging aft to the coach roof jam cleats with minimum friction.
ApplicationsSuch devices are used aboard sailboats with complex running rigging at the mast. They concentrate lines at a single point, facilitating short-handed maneuvers and reducing the need for crew to work at the foot of the mast.
TechnologiesOrganizers are often aluminum, but titanium models also exist. The sheaves, from one to four per organizer, can use ball or roller bearings. Some have double sheaves.
How to chooseChoice will depend on the diameter of the lines to be run through the organizer, whose rated working load must be respected.
