SEEMATZ Searchlight with electrical remote control. Remote controls are available for 24VDC, 110VAC, 230VAC, 440VAC input power. The input power from the control can be different from the searchlight.
|
|
SH 260, 310, 370. 470
Direct, bridge short or bridge high mount na.
24V-250W/500W/650W/1000W. 115V-1000W. 230V-1000 W. Halogen lamp
|
|
HR 250. 650-R20 Remote control. 24V-250W. 115V-250W. 230V-250W/650W. Halogen lamp
|
|
Features:
- 1 to 3 Million Candlepower (see Diameter-Sizes above)
- Remote Electric Beam-Size Focus (Option for 15-inch only)
- Unique Anti-shock Lampholder-Design helps prevent lamp filament damage due to excess vibration
- Exceeds 385 Degrees Horizontal Rotation with sliding stop design
- Rugged Brass and Stainless Steel Construction
- Weatherproof Design: Sealant surrounds Glass and Door is tightly sealed with gasket
- Voltages: 24VDC, 115 VAC and 230 VAC
- Finishes: Scratch-Resistant White Powder Coat, Polished Brass and Sparkling Chrome
- Aiming: Remote Lever, Lever-Gear and Local Handle
- Multiple Heights: Standard, Tall and Extra Tall Pedestals (manual control models only)
|
|
Features:
- 15 Million Candlepower
- 200 Watt Xenon Lamp
- Remote Electric Beam-Size Focus
- "Proportional-Speed" Joystick combines simultaneous Speed and Aiming Control with one hand...click here "Joystick"
- Electroformed Precision-Optic, made of virtually indestructible Nickel, produces a 1-degree beam collimation
- Unique Slip-Ring and Brush Design provides continuous, unlimited horizontal motion with no stop points
- Upside Down Mounting Option (must be specified by model number)
- Detachable Infrared Filter provides Covert Surveillance
- Compact Electronic Solid State Power Supply (Printed Circuit Board provides quick and easy swap-out, for troubleshooting)
- Marine Aluminum and Stainless Steel
- Scratch-Resistant Powder Coat Finish
- Voltages: 115VAC or 230VAC
- Multiple Controls...Weatherproof Options Available, and also Portable Hand-held Controls (Consult Factory for these options)
|
|
Features:
- 4.5 Million Candlepower
- Remote Electric Beam-Size Focus (optional)
- Unique Anti-shock Lampholder-Design helps prevent lamp filament damage due to excess vibration
- Exceeds 385 Degrees Horizontal Rotation (with unique sliding stop design)
- Rugged Marine Aluminum and Stainless Steel Material
- Weatherproof Design: Sealant surrounds Glass and Door is tightly sealed with gasket
- Voltages: 24VDC, 115 VAC and 230 VAC
- Scratch-Resistant and Salt-Resistant White Powder Coat Finish
- Aiming: Remote Lever, Remote Lever-Gear and Local Handle
- Heights: Standard or Tall Pedestal (manual control only)
- Optional Turntable Base... Slip-Ring and Brush Design provides continuous, unlimited and uninterrupted travel, with no stop points
|
|
SEEMATZ standard steering are available in two different dimensions.
The standard diameter for all columns will be 100mm. This type can be used for all
SEEMATZ searchlights in every area. Also available is a type with with 80mm
diameter. That one can be used for all SEEMATZ searchlights from 273 up to
463 HGS, but only in non polar areas.
Following steering types are available:
DS = deck short, searchlight direct on a mountingt foot
DH = deck high, searchlight on a pedestal with a standard length from 1000mm
WS = wheelhouse short, searchlight on a mounting foot with a 500mm column
into the bridge.
WH= wheelhouse high, searchlight on a 1000mm pedestal and 500mm column
into the bridge.
Every steering type is totally watertight and easily installed. After cutting a hole, the
column can be inserted smoothly into the vessel´s ceiling. This installation makes a
secure and elegant finish, even for wheelhouse roofs with thick insulation.
|
|
SH370,470.480.650-RS2
Remote control.
115V-2000W/3000W.
230V-1000W/2000W/3000W/5000W.
Halogen lamp.
|
|
SEEMATZ standard steering are available in two different dimensions.
The standard diameter for all columns will be 100mm. This type can be used for all
SEEMATZ searchlights in every area. Also available is a type with with 80mm
diameter. That one can be used for all SEEMATZ searchlights from 273 up to
463 HGS, but only in non polar areas.
Following steering types are available:
DS = deck short, searchlight direct on a mountingt foot
DH = deck high, searchlight on a pedestal with a standard length from 1000mm
WS = wheelhouse short, searchlight on a mounting foot with a 500mm column
into the bridge.
WH= wheelhouse high, searchlight on a 1000mm pedestal and 500mm column
into the bridge.
Every steering type is totally watertight and easily installed. After cutting a hole, the
column can be inserted smoothly into the vessel´s ceiling. This installation makes a
secure and elegant finish, even for wheelhouse roofs with thick insulation.
|
|
|
XS 500. 1000,1600-R10 Remote control. 115V-500W/1000W/1600W. 230V-500W/1000W/1600W. Zenon lamp.
|
|
Features:
- Drum-Size nominal 19-inch (483mm)
- 80 Million (1.0kw) and 150 (2.5kw) Beam Candlepower
- Nominal 1-degree Beam Spread Collimation
- Remote Electric Beam-Size Focus (1 to 15 degrees)
- External Manual Beam-Size Focus Knob (provides back-up if focus motor fails)
- Precision Electroformed Deep-Dish Reflector made of Bullet-Resistant Nickel with Polished Rhodium Finish
- Rugged Marine Aluminum and Stainless Steel Construction
- Voltages: 3-phase 208/240 VAC, 380 VAC, 480 VAC or 575 VAC
- Aiming: Remote Lever-Gear or Local Handle
- Searchlight Door Interlock Switch Shuts Off Power to System
- Scratch-Resistant and Salt-Resistant Powder Coat Finish
- Long-Life Warranted Xenon Lamp
- Sealed Weatherproof Drum
- Exceeds 385 Degree Horizontal Rotation (with unique sliding-stop design)
|
|
|
Suez Channel Searchlight with 2000 or 3000W. Compl. with 2x lamp, mounting foot and 3m cable with lockable plug. Airpressure Equipment available
|
|
|
Application: small to medium commercial vessels, large leisure craft land based secure facilities. Barrel, front ring and crutch are made of stainless steel, base made of corrosion-resistant LM6 aluminium, toughened soda-lime glass lens super purity aluminium mirror. All outside surfaces are white powdercoated, internal surfaces are optical matt black. Mounting variations look the table
|
|
Seawater resistant aluminium with structure coating in white
|
|
HR 250 R20 is very well suited for high speed vessels, tug boats, pilot vessels and luxury yachts, due to the clean compact design and its low weight.
Built with corrosion resistant components, and designed for extreme marine environments which require minimum maintenance.
Besides low weight and simple mounting, these searchlights provide reliable lighting in all kinds of temperature
|
|
Halogen searchlights SH 310, SH 470 and SH 480 are suitable for all kinds of ships.
The control system is based on TCP/IP technology were 9 different units of Xenon or Halogen searchlights can be connected to the same network through Ethernet cat 5 cables. It is stepless adjustable 360° horizontal and 55° tilting movements. There are several options of control panels both hard wired and wireless, which are fitted to standard solution.
Built with corrosion resistant components, and designed for extreme marine environments which require minimum maintenance. High quality seawater resistant aluminium housing finished in white polyester coating.
Low weight and simple to mount, these searchlights provide reliable lighting in all kinds of temperatures.
|
|
Material: Casing: stainless steel SUS 304 (1.4301)
Colour: Traffic white RAL 9016
Lamp: Halogen lamp
Parabolic mirror / reflector: Glass, Ø 300 mm
Light colour: Constant
Lighting performance: Immediate maximum light
Average lamp life: 75-200 h
Equipment:
- Toughened front glass
- Rubber sealing
- Quick fastening devices
- Connection cable =3m
- Anti dazzle screen
- External focusing
- WISKA's devices are built at least up to requirements of ABS, BV, DNV, GL, LR, PRS
Variations: Heating
Suitable for: Suitable for all kinds of seagoing vessels and on shore security.
|
|
Material: Casing: stainless steel SUS 304 (1.4301)
Colour: Traffic white RAL 9016
Lamp: Halogen lamp
Parabolic mirror / reflector: Aluminium, Ø 400 mm
Light colour: Constant
Lighting performance: Immediate maximum light
Average lamp life: 75-200 h
Equipment:
- Toughened front glass
- Rubber sealing
- Quick fastening devices
- Connection cable =3m
- Anti dazzle screen
- WISKA's devices are built at least up to requirements of ABS, BV, DNV, GL, LR, PRS
- Approval by China Classification Society
Variations: Heating
Suitable for: Suitable for all kinds of seagoing vessels and on shore security
|
|
Metal halide searchlight SHRI 1000 D/DH is suitable for all kinds of ships, especially vessels demanding high light output or operating in harsh winter/ice conditions such as tugs, icebreakers, offshore supply vessels or ice-classed vessels.
The performance of the Metal Halide light is similar to Xenon, though with a wider and shorter beam range.
Built with corrosion resistant components, and designed for extreme marine environments which require minimum maintenance. High quality seawater resistant aluminium housing finished in white polyester coating. Stainless steel forks and fittings.
The searchlight provides reliable lighting in all kinds of temperatures, has low weight and simple mounting.
Main control panel is included.
|
|
Protection class to EN 60 529: IP 56
Material: Casing: stainless steel SUS 304 (1.4301)
Colour: Traffic white RAL 9016
Lamp: Metal halide lamp
Focusing: Fixed focus
Parabolic mirror / reflector: Glass, Ø 400 mm
Auxiliary reflector: 100 mm
Light colour: Constant, high portion of blue colour, nearly daylight spectrum
Lighting performance: Maximum light after 45 sec., immediate reignition without cooling period
Average lamp life: 750 h
Power supply unit: PSUH
Equipment:
- Toughened front glass
- Rubber sealing
- Metal halide lamp 575W
- Quick fastening devices
- Ignition unit and stand-by heater
- Connection cable =3m
- Anti dazzle screen
- WISKA's devices are built at least up to requirements of ABS, BV, DNV, GL, LR, PRS
Suitable for: Suitable for all kinds of seagoing vessels, ideal for navigation in ice.
|
|
Protection class to EN 60 529: IP 56
Material: Casing: stainless steel
Colour: Traffic white RAL 9016
Lamp: Metal halide lamp
Parabolic mirror / reflector: Glass, Ø 300 mm
Auxiliary reflector: 100 mm
Light colour: Constant, high portion of blue colour, nearly daylight spectrum
Lighting performance: Maximum light after 45 sec., immediate reignition without cooling period
Average lamp life: 750 h
Power supply unit: PSUH
Equipment:
- Toughened front glass
- Rubber sealing
- Metal halide lamp 575W
- Quick fastening devices
- Ignition
- Connection cable =3m
- Anti dazzle screen
- WISKA's devices are built at least up to requirements of ABS, BV, DNV, GL, LR, PRS
|
|
|
Application: medium to large commercial vessels, land based secure facilities. Barrel, back plate and crutch are made of stainless steel, base made of corrosion-resistant LM6 aluminium, toughened soda-lime glass lens super purity aluminium mirror. All outside surfaces are white powdercoated, internal surfaces are optical matt black. Standard fitment heater, thermostatically controlled, electric remote focus. Mounting variations look the table.
|
|
XR 150 and XS 500 are very well suited for high speed vessels, tug boats, pilot vessels and luxury yachts, due to the clean compact design and low weight. All the components are chosen to withstand corrosion. The searchlights are designed for use in extreme marine environments and require a minimum of maintenance. Seawater-resistant aluminium housing finished with whitepolyester coating.
Benefitting from low weight and simple mounting, these searchlights are designed to operate across a wide range of temperatures. Integrated power supply on XR 150 R20. Control panel and power supply unit included.
|
|
Protection class to EN 60 529: IP 56
Material: Casing: stainless steel SUS 304 (1.4301)
Colour: Traffic white RAL 9016
Lamp: Xenon short arc lamp
Focusing: Fixed focus
Parabolic mirror / reflector: Glass, Ø 450 mm
Auxiliary reflector: 100 mm
Light colour: Constant, high portion of blue colour, nearly daylight spectrum
Lighting performance: Immediate maximum light, immediate reignition without cooling period
Average lamp life: 1500 - 2000 h
Power supply unit:
- PSUX
- PSUX-E (electronic)
Equipment:
- Toughened front glass
- Rubber sealing
- Quick fastening devices
- Ignition unit
- Stand-by heater
Suitable for: Suitable for all kinds of seagoing vessels, ideal for navigation in ice, particularly for securing and surveillance duties.
|
|
|
Application: medium commercial vessels, land based secure facilities. Barrel black plate and crutch are made of stainless steel, base made of corrosion-resistant LM6 aluminium, toughened soda-lime glass lens super purity aluminium mirror. All outside surfaces are white powdercoated, internal surfaces are optical matt black. Mounting variations look the table.
|
|
Material: Casing: stainless steel SUS 304 (1.4301)
Colour: Traffic white RAL 9016
Lamp: Halogen lamp
Parabolic mirror / reflector: Glass, Ø 400 mm
Light colour: Constant
Lighting performance: Immediate maximum light
Average lamp life: 75-200 h
Equipment:
- Toughened front glass
- Rubber sealing
- Quick fastening devices
- Connection cable =3m
- Anti dazzle screen
- Focusing
- WISKA's devices are built at least up to requirements of ABS, BV, DNV, GL, LR, PRS
- Approval by China Classification Society
Variations: Heating
Suitable for: Suitable for all kinds of seagoing vessels and on shore security.
|
|
Material: Casing: stainless steel SUS 304 (1.4301)
Colour: Traffic white RAL 9016
Lamp: Halogen lamp
Parabolic mirror / reflector: Glass, Ø 300 mm
Light colour: Constant
Lighting performance: Immediate maximum light
Average lamp life: 75-200 h
Equipment:
- Toughened front glass
- Rubber sealing
- Quick fastening devices
- Connection cable =3m
- Anti dazzle screen
- External focusing
- WISKA's devices are built at least up to requirements of ABS, BV, DNV, GL, LR, PRS
Variations: Heating
Suitable for: Suitable for all kinds of seagoing vessels and on shore security.
|
|
Material: Casing: stainless steel SUS 304 (1.4301)
Colour: Traffic white RAL 9016
Lamp: Halogen lamp
Parabolic mirror / reflector: Aluminium, Ø 300 mm
Light colour: Constant
Lighting performance: Immediate maximum light
Average lamp life: 75-200 h
Equipment:
- Toughened front glass
- Rubber sealing
- Quick fastening devices
- Connection cable =3m
- Anti dazzle screen
- WISKA's devices are built at least up to requirements of ABS, BV, DNV, GL, LR, PRS
Variations: Heating
Suitable for: Suitable for all kinds of seagoing vessels and on shore security.
|
|
Material: Casing: stainless steel SUS 304 (1.4301)
Colour: Traffic white RAL 9016
Lamp: Metal halide lamp
Focusing: Fixed focus
Parabolic mirror / reflector: Glass, Ø 450 mm
Auxiliary reflector: 100 mm
Light colour: Constant, high portion of blue colour, nearly daylight spectrum
Lighting performance: Maximum light after 45 sec., immediate re-ignition without cooling period
Average lamp life: 750 h
Power supply unit: PSUH
Equipment:
- Toughened front glass
- Rubber sealing
- Metal halide lamp 1200W
- Quick fastening devices
- Ignition unit and stand-by heater
- Connection cable =3m
- Anti dazzle screen
- WISKA's devices are built at least up to requirements of ABS, BV, DNV, GL, LR, PRS
Suitable for: Suitable for all kinds of seagoing vessels, ideal for navigation in ice.
|
|
Xenon searchlights XS 500, XS 1000, XS 1600, XS 2000 and XS 3000 are suitable for all kinds of ships. The control system is based on TCP/IP technology were 9 different units of Xenon or Halogen searchlights can by connected to the same network through Ethernet cat 5 cables. There are several options of control panels both hard wired and wireless, which are fitted to standard solution.
All the components are chosen to withstand corrosion. The searchlights are designed for use in extreme marine environments and require a minimum of maintenance. Seawater-resistant aluminium housing finished with white polyester coating. Stainless steel forks and fittings.
Benefiting from low weight and simple mounting, these searchlights are designed to operate across a wide range of temperatures.
|
|
|
|
