The C40 has long been the mainstay of our charge controller line-up, its versatility and reliability have made it an industry standard. Now the C40 is joined by two companion controllers, the C35 and C60.
|
|
|
To avoid overcharging your battery. Perfect match for solar panels generating up to 10A of current. Charging 12V battery systems. Intelligent PWM charge control ensures batteries reach max capacity. Built-in LED indicator instantly displays charging status
|
|
|
To avoid overcharging your battery. Perfect match for solar panels generating up to 20A of current. Charging 12V battery systems. Integrated display gives you information on the battery status
|
|
|
The new EOS® controller is easily installable into existing circuit thanks to a wiring connection RS485 or wireless protocol (available on demand) and can be interfaced with integrated electronic management systems.
|
|
|
|
|
|
|
NAVYLEC BATTERY MONITOR NL208-12X
Precision LEDs voltmeter’s for 12V batteries with alarm and relay
(size B2 W.80 x H.80mm)
For 1, 2 or 3 12V batteries
Batteries monitored simultaneously
Audible, light and relay alarms
Instant visualization
Direct interpretation of the measure
Measurement accuracy of 10mV
LEDs voltmeter compact 80x80mm
Very low consumption
The high-end LEDs voltmeter NAVYLEC NL208-12X can measure the voltage of one or more independent batteries in the form of light.
The supervisory function of each battery bank can trigger an audible, a visual and a relay alarms when it is activated.
• Scale bright with 9 LEDs between 9,5 and 15,2V. The distribution of LEDs provides an accurate indication of the battery’s state.
• A specific marker (alternator) can instantly verify the proper functioning of battery charge system.
• Instant reading of the measure on the LEDs.
• Models 2 and 3 batteries can instantly give the read on the status of each battery connected.
• An Audible alarm, visual and by relay is integrated. It activates, turns off or stopped by the push button.
• The domestic consumption of the unit is extremely low running. To further reduce it, this consumption is partitioned into different batteries for versions 2 and 3 batteries.
• The front panel is waterproof and the electronic components are drowned in the resin.
Its small size (80x80mm) allows an easy installation on any existing panel or near the battery to be controlled.
Recommended for any batteries measures : main battery bank, engine, bow thrusters, electronic, auxiliary, etc
|
|
|
|
|
|
|
The high-end LEDs voltmeter NAVYLEC can measure the voltage of one or more independent batteries in the form of light and use the EL Electroluminescence Lighting technology for his serigraphy back lighting.
The supervisory function of each battery bank even when the monitor is shut down can trigger an audible and visual alarm when it is activated.
Large scale bright with 16 LEDs between 9,5V to 15,2V and 19V to 30,4V for the 24V versions. The distribution of LEDs provides an accurate indication of the battery's state.
Display of EL on serigraphy can be command separately (with the navigation lights, for example).
1, 2 or 3 buttons allow the display selection of the battery to be viewed.
An audible alarm is integrated and bright / triggered by the low voltage level or the high voltage in each battery bank connected.
The modus operandi of the device can be defined depending of the use: permanent mode, timed or on/off mode.
The domestic consumption of the unit is extremely low running even with the EL and even more in sleep mode. To further reduce it, this consumption is partitioned into different batteries for versions 2 and 3 batteries.
A specific marker (alternator) can instantly verify the proper functioning of battery charge system.
The front panel is waterproof and the electronic components are drowned in the resin.
|
|
The high-end LEDs voltmeter NAVYLEC can measure the voltage of one battery in the form of light.
The supervisory function of each battery bank can trigger an audible, a visual and a relay alarms when it is activated.
|
|
The high-end LEDs voltmeter NAVYLEC can measure the voltage of two independent batteries in the form of light.
The supervisory function of each battery bank can trigger an audible, a visual and a relay alarms when it is activated.
|
|
|
|
|
|
|
The high-end voltmeter with LCD display NAVYLEC can measure the voltage of one or more independent batteries in the form of light and use the EL Electroluminescent lighting technology for his serigraphy and the LCD display back lighting.
The supervisory function of each battery bank even when the monitor is shut down can trigger an audible and visual alarm when it is activated.
LCD precision voltmeter's with electroluminescent back lighting
12 or 24V
Running on circuits 12V or 24V without adjustment to do.
Electroluminescent EL lighting of the serigraphy and LCD display.
The LCD screen display makes reading instant of the battery voltage measured on four-digit.
Display of EL on serigraphy can be command separately (with the navigation lights, for example).
1, 2 or 3 buttons allow the display selection of the battery to be viewed.
An audible alarm is integrated and bright / triggered by the low voltage level or the high voltage in each battery bank connected.
The functioning mode of the device can be defined depending of the use: permanent mode, timed or on/off mode.
The domestic consumption of the unit is extremely low running even with the electroluminescence EL and even more in sleep mode. To further reduce it, this consumption is partitioned into different batteries for versions 2 and 3 batteries.
The front panel is well protected and the electronic components are drowned in the resin.
|
|
|
|
|
|
|
For Deep Cycle Batteries used in Marine, RV, camping, off-road, military, emergency vehicles, construction equipment, electric vehicles, industrial battery equipment, and other deep cycle battery applications.
Optimize performance and extend battery life.
Deep Cycle batteries supply electric power for extended periods of time. It is often critical to understand just how much energy is in a battery so you can use it with confidence or know when to recharge. The microprocessor of the BB-DCM series uses LPR to measure battery internal resistance every minute and calculates available stored energy. An analog 'battery fuel gauge' indicates how full the battery is. Visual icons and audible alarms indicate when it is time to recharge.
Replace your battery before it fails.
Even a well maintained battery loses capacity over time and eventually it will not be able to store enough energy to do its job. The BB-DCM is the first and only monitor to track battery state of health deterioration while the battery is in use. When storage capability drops to a critical level, visual and audible alarms warn you to replace the battery.
The BB-DCM mounts in seconds to the battery surface and connects to the battery terminals. The information-packed LCD display shows battery state of charge (energy fuel gauge), state of health / battery life, and battery voltage. Visual and audible alarms indicate low charge / recharge, and end of life / replace battery conditions.
|
|
You’re out on the water kicking back, listening to your favorite tunes, while enjoying family and friends. You wish it could never end. Then when it’s time to head in you realize, the battery is drained and you’re stuck. Don’t let this
happen to you. A dead battery can be a real hassle and worse, this could turn into a dangerous situation.
|
|
| ... products without information |
| |
The C40 has long been the mainstay of our charge controller line-up, its versatility and reliability have made it an industry standard. Now the C40 is joined by two companion controllers, the C35 and C60.
|
|
| ... products without information |
| |
| ... products without information |
| |
|
The BSW 1000 by Smartswitch has been designed to counter the design failings of bilge switches of yesterday. Short life span and unreliability caused by switches continuously burning-out was almost ‘par for the course’. NOT ANYMORE. Easy to install and easy to operate, the BSW 1000 offers today’s mariner a reliable alternative to the old technology still on the market today.
|
|
|
|
