aqua signal ISLAND – effective
Voltage:
12 V, 24 V, 230 V
Housing:
Stainlees steel, powder coated white, non-corrosive, non-magnetic, seawater resistant
Diffuser:
Clear safety glass
Protection:
IP 67
Electric:
Cable entry brass M18 x 1,5 MGCG, 1,5 m cable
Authorisation:
CE
|
|
This adjustable light for Low/High level fitting with a 15mm glass can be surface mounted or flush mounted and needs to be used with an aluminium or stainless steel insert. It is suitable for all exposed areas.
The light uses the best quality material and the bolted bezel is manufactured from 316 stainless steel.
It has been tested for water tightness to IP56. The 15mm glass can either be ordered with a clear or frosted finish depending on how much light is required.
TECHNICAL SPECIFICATION
Lamp type - MR 16 halogen
Insert - Alu. ( S34443) or S. Steel (S34444)
Bezel Finish - bolted 316 stainless steel
Glass lens finish - clear or frosted (15mm)
IP Rating - IP 56
Voltage
|
|
The PAR 30 Adjustable flood light with bolted bezel is used for exterior flood lighting onto areas such as decks or masts.
The fitting accomodates a 15mm thick borosilicate glass for installation into areas open to heavy weather and requires an insert to be welded onto the superstructure. The inserts are manufactured in Aluminium 5083
(part number S23061-A) or in 316 Stainless Steel ( Part number S23062-A).
The light is available with a 150w metal halide bulb- max 150w - or with a halogen bulb -max 75w - The electronic ballast for the metal halide fitting is remote from the lamp.
The maximum distance from the ballast to the lamp is 10 meters.
The light has been tested for water tightness (front face only) to IP 56.
|
|
Oval Low/High Level Adjustable Flood Lights
This oval low or high level lights with twin flood lamp can be installed almost anyway except exposed areas or below the ‘maindeck’. This versatile light could also be used as a down light.
Application: Decks, overheads and bulwark lights
Bulbs: Two MR11 20 watt halogen lamps. Maximum total 40 watts or 3 x 8.5 watt lamps
Power Supply: 12/24 Volts and 120 or 230 Volts is available with and external transformer
Bezel Material: Polished Stainless steel
Lens: Clear or frosted glass
|
|
MR11 and MR16 Surface Mounted Lights
The exterior MR11 and MR16 deck lights are surface mounted and have been tested to IP65. The lights are available in two different sizes with a screwed or bulkhead fitting. Both lights are manufactured in a polished stainless steel and can be installed in most places which need direct lighting.
Application: Decks, bulkheads and overheads
Bulbs: Halogen low voltage
Power Supply: 12/24 volts. MR 16 35 watt maximum and MR11 20 watt maximum
Casing Material: Polished Stainless steel
Lens: Clear
|
|
MR16 Low and High Level Flood Lights (S3025B and S3052S)
This particular light is available with two different depths of glass. The light with the 4mm thick glass bezel is suitable for fitting into exterior deck heads and superstructure not exposed to heavy weather. For areas exposed to heavy weather, the light is fitted with a 15mm glass bezel. Installation requires an insert, available in both aluminium and stainless steel, so the lights is flush.
Application: Decks, steps and masts
Types of Bulb: Halogen, MR16 50 watt maximum.
Power Supply: 12/24 or 120/230v which requires a transformer
Insert Material: Aluminium or stainless steel
Bezel Option: Bolted or screwed
Lens: Clear or frosted, 4mm or 15mm thick available
|
|
- Bracket, surface, tower and flush mounting
- 45º
- x 20º
- flood beam pattern
- 3" x 5" Bulb
- Internal weather-proof wire splicing - no connectors required
- Vertical and horizontal head adjustment
|
|
- Dual lamp design provides redundancy, reliability-works when you need it
- Bright, powerful halogen beam with 3° h x 5° w beam spread
- Easy-to-install Point Pad™-style joystick control
- Robust, function-and feature-rich searchlight is easy to install
- 7-wire wiring harness, 17' length
- Electronics located in water-resistant light head, instead of traditional light base location, for protection from water accumulation
- 45° down pitch ocular design provides enhanced visibility when docking
- 18° up pitch to illuminate draw bridge towers, etc.
- Lamps easily replaced by removing top cap to access rear light assembly
- Desiccated filter dries air; protects reflector and light assembly
- Innovative "direct drive" system eliminates uncontrolled light movement in choppy conditions
- Heavy-duty gear teeth and electric motors
|
|
Application:
For the marine industry
Materials:
- Housing, chromatted seawater resistant aluminium
- All other materials corrosion resistant and non-magnetic
- Finish: UV-resistant powder coating, white RAL 9016
Optics:
- Hardened front glass
- Parabolic mirror Ø 260 mm with adjustable focus
|
|
- Constructed of noncorrosive materials.
- Sealed beam halogen lamp.
- Long life gear drive.
- Low amp draw.
- Patented clutch mechanism prevents motor damage when running against limit stops.
- Remote Control and 15' cable included.
|
|
Features:
- Constructed of noncorrosive materials.
- Sealed beam halogen lamp.
- Long life gear drive.
- Low amp draw.
- Patented clutch mechanism prevents motor damage when running against limit stops.
- Remote Control and 15' cable included.
|
|
|
Sunnex HT Spot is a small, handy 10W halogen light that provides powerful spot lighting. Sunnex HT Spot is available in a 230V version with an electronic plug-in transformer, and in a 12V or 24V version for direct connection to low-voltage equipment. Sunnex HT Spot has an articulated lamp head for easy positioning. Thanks to its ergonomic design, the whole light is easy to clean.
|
|
Sunnex HT Spot Light ? 20W
This compact model is a safe, low voltage 20W spot light designed for direct connection. While all spot lights are low voltage, an integrated transformer can be provided by special request on certain models. A remote transformer is also available. The HT Spot Light is ideal as chart reading light, cabin light and for pilot seat controls.
Features include:
12V or 24V with 20W halogen bulb
Direct or rectangular mount base
Rocker switch on base
Available in black or white
|
|
aqua signal Calais - Halogen recessed downlight.
Voltage:
12 V
Housing:
Plastic, available with chrome, brass and white finish
Versions:
Flexible and fixed versions, Halogen G4 20W
|
|
aqua signal Atlanta - maritime light applications in surface and recessed mounting versions for halogen or festoon bulbs. Atlanta Ring stainless steel. Incl. 100 mm / 3.94’ cable
Voltage:
12 V, 24 V
Housing:
Metal
Diffuser:
Plastic, seawater resistant
Protection:
IP 56
|
|
Savage Marine also specialise in Interior & Exterior lighting for exclusive Hotels and luxury Architectural developments, whatever your requirements or designs Savage Marine can help, call our sales team today. Bespoke lighting a speciality.
|
|
The New Polymer Range
Made from an exotic high temperature, electroplatable injection moulded Polymer, not only are they Super Light Weight, they also run up to 30 degrees cooler than normal Brass or Stainless Steel fittings. They are non-corrosive, very competitively priced, whilst still being an exceptionally high quality product.
Using the highest grade raw materials, V0 rated Injection moulded Glass Filled Nylon back bodies, toughened Borosilicate glass for our lenses and Ceramic Double contact halogen lamp holders.
|
|
|
|
