The punching modules are used to punch leather, rubber, and various textiles remarkably fast. This module includes independently operating punches that accommodate a variety of punch tools. The punches rotate as they penetrate the material, which creates cleanly and precisely cut holes even in tough materials up to approx. 6 mm thick. Advantages of this processing method are high capacity and very good, consistent hole quality.
Excellent, consistent hole quality
Up to 8 holes per second
Wide assortment of 0.5 – 5.5 mm Ø punches available from Zünd
Reliable waste removal into integrated receptacle
Depending on module version, additional notching, marking, or piercing functions
The Punch and Pricking Module offers a combination of high-performance tools for punching and piercing leather, rubber, andtextile materials.
The Punch and Pricking Module is used for leather, rubber, and a variety of textiles – performing all functions with amazing speed!
This module includes three high-performance, independently operating punches that allow
for using two different punching bits plus an awl at any given time. The punching bits and
awl are precisely positioned and pressed into the materials with pneumatic force.
Punching: rotating punching bits are designed to cut clean, precise holes even in tough
materials up to 6 mm thick. Advantages of this processing method are high capacity and very good, consistent hole quality.
To meet different requirements, punching bits made of hard metal (HM) or high-speed steel (HSS) are available, with hole diameters of 0.5 – 5.5 mm.
