Heavy Duty & Commercial Pontoons We offer a range of options to customers seeking high-specification pontoons for exposed locations, larger leisure boats and superyachts, and commercial / public sector applications. Commercial and working harbour pontoons will exhibit higher live loadings and will be designed to resist greater berthing forces than standard marina pontoon equipment. Our heavy-duty units can range from upgraded standard pontoons which benefit from additional buoyancy, reinforced frames and higher freeboard together with more substantial timber or concrete decking through to continuous buoyancy, steel or all concrete floating structures offering wave attenuating characteristics. Jumbo pontoon In its standard form, the Walcon Jumbo pontoon measures 11 metres by 3 metres and has an unladen freeboard of 750mm and a live load of 2.5 kN/m². Construction is in mild steel with an all welded structure galvanised to EN ISO 1461 and it features side channels measuring 260mm. The buoyancy for each unit is provided by six, extra-deep, Walcon fibre concrete protected expanded polystyrene floats arranged in a catamaran layout. Waliflote Waliflote is a heavy-duty steel commercial pontoon and continuous buoyancy concrete flotation unit for the safe loading of marina services and equipment. The original Waliflote floating pontoon unit was developed for the heavy services loading that was required for the Brighton marina pontoon facility. The design has since evolved and is now supplied with either a concrete pontoon deck finish with hardwood fenders or a traditional pontoon finish with a galvanised steel frame clad in hardwood timber boards and fenders.
