Catamaran sailing yacht 510

cruisingcharter4-cabin

Overview
The VOYAGE 510 is a 15.8 m (51'10") catamaran designed for blue-water cruising and high-efficiency sailing. Delivered in 2025, the platform balances onboard comfort, seaworthiness and operational systems suitable for private ownership or commercial charter operations.

Key features

• Performance hulls with attention to seakeeping and reduced resistance.
• Efficient sail plan and deck layout for short-handed handling.
• Spacious saloon and cockpit arrangements for extended cruising comfort.

Video Tour
Detailed video walkthrough available showing interior layout, deck plan, systems and underway performance.

Dimensions

• Length Overall (LOA): 51' 10" / 15.8 m
• Beam: 26' 11" / 8.2 m
• Draft: 4' 11" / 1.5 m
• Displacement: 42,990 lbs / 19,500 kg

Engines

• Engine Brand: Yanmar
• Engine Model: 4JH57
• Power: 57 HP each
• Engine Hours: 850

Tankage

• Fuel: 238 gal / 900 L
• Fresh water: 238 gal / 900 L
• Holding tank: 185 gal / 700 L

Accommodations

• Cabins: 4
• Heads: 4
• Berths / Sleeps: 8-10

Sailing

• Main sail area: 1,044 sqft / 97 m²
• Genoa: 592 sqft / 55 m²
• Cruising speed: 9 knots

Plumbing

• Automatic electric bilge pumps with high-level alarms: 4
• Black water systems and holding tanks: 2
• Pressurized hot and cold freshwater system with 2 pumps
• Deck shower (hot/cold) at port transom

Electrics

• 24V/12V DC distribution
• Victron shore power charger
• 50A/240V shore power socket
• Battery isolator switches and BLUE SEA DC circuit breaker panel
• Victron 24V house bank 600 Ah (3.6 kW)

Composite Construction

• High quality polyester resin and multi-layer quadriaxial glass fabric
• GRP hand lay-up combined with infusion technology
• Bulkheads tabbed to hull, deck and coachroof; forward watertight compartments
• Underwater body coated in anti-osmotic epoxy

Rigging

• Sparcraft 7/8 fractional rig
• Anodized aluminum mast, boom and cross beam
• Single spreaders with intermediate and cap shrouds
• Double purchase main halyard, color-coded control lines led to helm
• Mainsheet system, lazy jacks and deck lighting

Deck Equipment

• ANDERSEN 52ST manual winches x3
• Stainless steel mooring cleats x10
• HARKEN blocks, tracks and cars
• SPINLOCK jammers and rope organizers

Mooring Gear & Ground Tackle

• Lofrans 2300W / 24V windlass
• Delta anchor 50 kg with 12 mm chain (80 m) and 60 m nylon rode
• Anchor bridle with thimbles; two anchor rollers (one with tipper)

Technical specifications

• Model: VOYAGE 510
• Brand: VOYAGE
• Year: 2025
• Type: Catamaran
• Price (starting): 2,450,000 USD (excl. tax)
• LOA: 51' 10" / 15.8 m
• Beam: 26' 11" / 8.2 m
• Draft: 4' 11" / 1.5 m
• Displacement: 42,990 lbs / 19,500 kg
• Engines: Yanmar 4JH57, 57 HP each, 850 hrs
• Fuel / Water: 238 gal / 900 L each
• Holding tank: 185 gal / 700 L
• Cabins / Heads: 4 / 4
• Sleeps: 8-10
• Main sail: 1,044 sqft / 97 m²; Genoa: 592 sqft / 55 m²
• Cruising speed: 9 knots
