Boat drive shaft universal joint S Series

The S Series is the basic version of Voith universal joint shafts. It has been de­signed for small- to medium-sized drives. The connection flanges are friction flanges. In building the S universal joint shafts, we use high-strength tempered and case-hardened steels that assure a very good capability to withstand static and dynamic loads. The universal joint shafts have high torque capacity combined with optimal bending and torsion rigidity. Our experts choose the universal joint shaft that precisely matches your application. We don't just consider the load data of the universal joint shaft, we also look at the resonance ranges that are critical for flexure and torsion. Your universal joint shaft is operationally reliable and has a long lifetime. Low maintenance costs further im­prove the life cycle costs of your machine or system. If necessary, we can adapt the design layout of our universal joint shafts to your drive and operating conditions. Technical data Torques with a single load MZ up to 35 kNm Torques with a reversing load MDW up to 11 kNm Deflection angle up to 35° Rotation diameter of the joints 52 mm – 204 mm Connections Friction flanges Center section Steel Length compensation None (fixed-length shaft) Telescopic (involute profile)
