Ultrasonic thickness gauge Smartor

Upgradeable One-hand Operation Flat Weld Simulation Smart Test Wizard IP 66 Compact size: 198 (W)* 128 (H) *52 (L) mm Light weight: 0.9kg only, including battery 5.7" LCD with high resolution 640×480 pixels Ultrasonic testing functions： √ Standard: Weld/ plate/ forging test wizards, DAC, AVG/ DGS, AGC (Auto gain control), peak memory, video record, etc. √ Optional: B-Scan, TCG, FFT (probe spectral analysis), CSC (curved surface correction), flat weld simulation, crack height measurement, BEA (backwall echo attenuator), AWS, API 5UE. Ultrasonic thickness measurement functions： √ Standard: A-scan thickness measurement (echo to echo mode, through coating measurement), auto-search, velocity measurement, alarm and dataset management. √ Optional functions: CoatMode, B-Scan, multilayers, Vpath, TDG and temperature compensation.
