beacon buoy / high seas / with signal light
Trident-2600

{{requestButtons}}

Characteristics

  • Type:

    beacon

  • Use:

    high seas

  • Other characteristics:

    with signal light

Description

2600mm Diameter Ocean Buoy (Trident-2600)
The float section of the Trident-2600 is made up of four rotationally moulded quadrants, which fasten together to form an incredibly robust 2.6 metre wide float section standing 1.5 meters tall. The enhanced poly-tower design provides a huge visual area for navaid recognition, and consists of a sealed, rotationally moulded tower section which incorporates an internal radar reflector and solar mount facility.

The unique design of the mooring post and flat base means the buoy can be stored upright in service yards and transported via truck and service vessels for increased handling safety.

FEATURES

2.6mtr diameter & up to 5mtr focal height
Robust construction of 4 quadrant hull sections
Convenient forklift access points to safely manoeuvre the buoy assembly
Stands flat on service vessel deck
High visibility red, green, white or yellow as per IALA recommendations
Excellent buoyancy & stability
Easy to deploy & service
Lightweight
No painting, ever
Cost effective & environmentally friendly

OPTIONS

Mould-in graphics
Day marks
Monitoring systems (AIS, GSM)
Unfilled float section
Name plate
Aluminium tower assembly
Mooring solutions available include chain or synthetic, hardware and sinkers
Galvanised or stainless steel mooring post
Tall tube mooring post
