Handling trailer SW10
launchingfor boatfor shipyard

handling trailer
handling trailer
handling trailer
handling trailer
handling trailer
handling trailer
Add to favorites
Compare this product


handling, launching
for boat, for shipyard
Number of axles
Other characteristics

Max.: 10 t (11.02 us ton)

Min.: 0 t (0 us ton)

Overall length

8.2 m (26'10")

Overall width

2.2 m (7'02")

Lifting height

Max.: 1.7 m (5'07")

Min.: 0.7 m (2'03")


Frame High Grade S355 Steel, open U design Wheels, 4 pneumatic or 4 solid tires. Drawbar, 1,0 mtr. extendable. Pads, 2 polyurethane pads 930x320 mm. High quality hydraulic cylinders with safety valves built-in. Paint system, 2 coats epoxy primer and 2 coat 2 component topcoat, RAL color. The Hydrotrans hydraulic SW series boat trailer is designed to launch and recover boats on a slipway, transport the boats over land and park them in storage or work area. The Hydrotrans SW10 can be pulled by a forklift, or an agricultural tractor. It uses the hydraulic capacity of the tow vehicle for all the hydraulic functions. The boat is lifted by 2, or with an optional 4, hydraulic or mechanical pads with durable rubber pads on them to avoid damaging the hull. The front of the boat is supported by the crossbeam also with a rubber pad on it to avoid damage. For sailboats an adaptor is available, and an adaptor for catamarans is also available. The width of the trailer frame and the height are adjustable. The pads and drawbar are manually or hydraulically adjustable. The Hydrotrans SW series trailers are also suitable for transporting boats on T-cradle’s. With solid or pneumatic tires, the SW trailer offers optimal comfort through any terrain capable of carrying the load. The Hydrotrans SW trailers are built according to CE-regulations and are tested at the factory before shipment. All Hydrotrans equipment can be built to SAE specifications. Height on pads, 750 mm. Height on front, 430 mm. Distance between centre of pads, 1200-2000. Lifting height frame, 700 mm. Lifting height pads, 400 mm.


2 Pages
