Patrol boat HY830-Alu

outboardaluminumrigid hull

Product Overview
Professional 27 ft (8.30 m) aluminum patrol boat HY830-Alu designed for maritime patrol, search and rescue (SAR), beach landing support and commercial transport. Fully welded marine-grade aluminum hull and internal skeleton with a solid closed-cell EVA foam collar spray-coated in polyurea around the gunwale for permanent buoyancy and impact resistance. The 23° deep‑V hull improves seakeeping, reduces slamming and delivers a drier ride. Rated for twin outboard configurations and up to 10 persons.

Key Features

• 100% welded marine-grade aluminum hull and internal aluminum skeleton for structural strength
• Polyurea-coated solid EVA foam collar providing permanent buoyancy and high impact protection versus inflatable tubes
• 23° deep‑V aluminum hull for efficient wave cutting and improved seakeeping
• Designed to carry up to 10 persons; supports twin outboard engines (recommended twin 225 HP)
• Integrated 450 L fuel tank for extended operational range

Polyurea-EVA Collar Benefits

• Permanently buoyant closed-cell EVA core: vessel remains afloat if outer coating is compromised
• High impact absorption for pier landings and beaching operations
• Zero maintenance compared with inflatable Hypalon/PVC collars
• Excellent resistance to UV, saltwater and abrasion; closed-cell core does not absorb water

Applications

• Maritime patrol and security
• Search and rescue (SAR)
• Beach landing and shallow-water deployment
• Coastal defense, transport and logistics

Dimensions

• Model: HY830-Alu
• Length overall: 8.30 m / 27.2 ft
• Width overall: 2.86 m / 9.38 ft
• Inside width: 2.16 m / 7.09 ft
• Waterline length: 7.54 m / 24.74 ft
• Design waterline (draft): 0.50 m / 1.64 ft
• Deck length: 5.60 m / 18.37 ft
• V-shape (deadrise): 23°
• Category: C, B

Capacity

• Capacity: 10 persons
• Max loading: 1200 kg
• Net weight (boat without engines): 2380 kg
• Full load displacement: 3600 kg

Outboard Engine

• Engine shaft: XL 25"
• Recommended power: 225 HP × 2
• Max recommended power: 250 HP × 2 (confirm with factory if using max power)
• Fuel tank: 450 L

Shipment

• 40FT HQ container: 2 pcs per container (solid D-type fender may be removed for transport; if fender installed and secured, frame transport required)

Additional Operational Notes

• Polyurea applied by plural-component spray system to controlled thickness for abrasion and UV resistance
• Hull and keel reinforcements exceed typical patrol-class minimums; TIG/MIG welding by certified operators
• Recommended maintenance interval for professional users: every 50 hours or 6 months, whichever occurs first
• Permanent buoyancy from closed-cell EVA core ensures flotation if outer skin is damaged

Specifications

• Model: HY830-Alu
• Brand: Liya Boat
• Code: 8903.190000
• Length overall: 8.30 m / 27.2 ft
• Width overall: 2.86 m / 9.38 ft
• Inside width: 2.16 m / 7.09 ft
• Waterline length: 7.54 m / 24.74 ft
• Design waterline (draft): 0.50 m / 1.64 ft
• Deck length: 5.60 m / 18.37 ft
• V-shape (deadrise): 23°
• Capacity: 10 persons
• Max loading: 1200 kg
• Net weight (boat without engines): 2380 kg
• Full load displacement: 3600 kg
• Engine shaft: XL 25"
• Recommended power: 225 HP × 2
• Max recommended power: 250 HP × 2
• Fuel tank capacity: 450 L
• Construction: 100% welded marine-grade aluminum hull and internal skeleton (5083-H116 referenced)
• Fendering: Solid EVA foam collar with polyurea spray coating (closed-cell foam core)
• Classification / Use: Designed for patrol, SAR, beach landing, transport and commercial work
