Patrol marine drone HV160Y

for aquacultureautonomousremote-controlled

Product Brief
HV160Y is an unmanned aquaculture USV designed for automatic post-throw feeding, spraying and water-quality monitoring. Paddle-wheel propulsion and a 110 L feed container make it suitable for shallow-water shrimp and crustacean farms.

Overview

• Paddle-wheel drive optimized for shallow aquaculture ponds and cages
• Automatic post-throw feeding with integrated feed machine
• Combined functions: feeding, spray/medication and aeration support
• 110 L feed container; remote operation via radio control
• Typical endurance up to 8–10 h depending on speed and payload

Technical Details
Type: HV160Y
Length × Width × Height: 1.6 × 1.05 × 0.9 m
Material: FRP
Feed container capacity: 110 L
Load capacity: 80–100 kg (model/configuration dependent)
Draught: < 0.2 m
Max speed: up to 4 kn (approx. 2 m/s)
Cruising endurance: up to 10 h at ≤1 m/s (typ. 8–10 h)
Remote control range: standard 500 m–1 km; optional communication module can extend range to ~5 km

Standard / Optional Equipment

• Standard: Paddle wheels — 2 sets
• Standard: Feed machine — 1 set (110 L hopper)
• Standard: Radio remote control — 1 set
• Optional: Webcam — up to 2 units
• Optional: Spray/liquid dosing machine — 1 set
• Optional: Extended communication module for increased range

Product Description
Series: Unmanned boat
Brand: HVON
Model: HV160Y
Color: as shown in photos
Description: The HVON HV160Y is a paddle-wheel aquaculture USV for automatic post-throw feeding, spraying and water monitoring. Compact FRP hull and a 110 L feed tank enable efficient operations in shallow farming sites and cage systems.

Features / Technical Specifications

• Paddle-wheel propulsion suitable for shallow, soft-bottom environments
• Precise post-throw feeding (typical accuracy ±0.5 m depending on conditions)
• Multifunctional: feeding, medication/spraying and aeration support
• Onboard water-quality monitoring: temperature, pH, dissolved oxygen, ammonia nitrogen (sensor options)
• Remote operation and configurable autonomous routes; optional CCTV monitoring
• Compact dimensions for easy deployment and maintenance (1.6 × 1.05 × 0.9 m)
• FRP hull for corrosion resistance in aquaculture environments
