Modular floating dock module MP-series

Overview
Pontoon float designed for floating marina systems. The floats are rotomolded from polyethylene (PE). Models MP80, MP200 and MP420 include polystyrene foam as secondary buoyancy, which helps maintain flotation if the outer shell is damaged.

Applications and benefits

• Suitable for marina manufacturers and DIY installations
• Standardized models reduce development time and costs during the installation phase
• Polystyrene secondary buoyancy provides temporary flotation in case of outer-shell breach (MP80/MP200/MP420)

Product variants

• MP80 — Volume: 80 L; Weight: 10 kg; Net buoyancy: 70 kg; Height: 59 cm; Length: 70 cm; Width: 22 cm; Product sheet: MP80 (PDF)
• MP200 — Volume: 200 L; Weight: 18 kg; Net buoyancy: 182 kg; Height: 54 cm; Length: 140 cm; Width: 25 cm; Product sheet: MP200 (PDF)
• MP420 — Volume: 420 L; Weight: 30 kg; Net buoyancy: 390 kg; Height: 55 cm; Length: 175 cm; Width: 50 cm; Product sheet: MP420 (PDF)
• MP1100 — Volume: 1100 L; Weight: 50 kg; Net buoyancy: 1050 kg; Height: 79 cm; Length: 143 cm; Width: 98 cm; Product sheet: MP1100 (PDF)

Technical specifications

• Material: Rotomolded polyethylene (PE)
• Secondary buoyancy: Polystyrene foam (applies to MP80, MP200, MP420)
• Suitable for: Marina manufacturers and DIY
• Available types: MP80, MP200, MP420, MP1100

Customization & ordering
Custom molding for specially designed pontoon floats is available on request. Contact the supplier for technical drawings, lead times and product sheets.
