Ship attitude and heading reference system WSC-70

for merchant ships

Overview
The WSC-70 satellite compass uses multi-constellation GNSS to deliver position, heading and dynamic attitude data for marine navigation systems. It is designed for installation on yachts, fishing vessels, bulk carriers and unmanned boats.

Tags

• Fishing vessel
• Yacht
• Bulk carrier
• Unmanned boat

Display / Type
Display: Included / Not included
Type: Bracket

FEATURES
Provides continuous heading and attitude outputs with GNSS-based baseline measurement. Supports simultaneous tracking of multiple GNSS constellations and fast time-to-first-fix. Designed for marine installations with ±60° attitude range and stainless steel housing.

PARAMETER
Satellite system: 1408 chn, BDS/GPS/GLONASS/Galileo
Navigation system: BDS: B1I、B2I、B3I
GPS: L1C/A、L2C
GLONASS: L1、L2
Galileo: E1、E5b
Base length: 60cm
Heading accuracy: 0.2°RMS
Dynamic attitude accuracy: 0.1°RMS
Attitude angle range: ±60°
Positioning accuracy: 1.5m
Speed accuracy (3D): 0.05m/s
Cold start positioning time: <30s
Hot start positioning time: <5s
Weight: 7 kg
Material: Stainless steel

OPTIONS
Display: Included / Not included
Type: Bracket
Output:

• Heading, turning rate, ground speed/heading, roll, pitch, etc.
• Optional: heave, sway, surge

ACCESSORIES
(Accessory list available on product page if any)

Technical specifications

• Satellite system: 1408 channels; supports BDS / GPS / GLONASS / Galileo
• Navigation signals supported: BDS B1I/B2I/B3I; GPS L1C/A, L2C; GLONASS L1, L2; Galileo E1, E5b
• Base length: 60 cm
• Heading accuracy: 0.2° RMS
• Dynamic attitude accuracy: 0.1° RMS
• Attitude angle range: ±60°
• Positioning accuracy: 1.5 m
• Speed accuracy (3D): 0.05 m/s
• Cold start positioning time: <30 s
• Hot start positioning time: <5 s
• Weight: 7 kg
• Material: Stainless steel
