Boat indicator NT1550 Panoramic RAI

rudder angleanalog

The NT1550 Panoramic RAI is the newest addition to Navitron’s comprehensive range of MED Type Approved Rudder Angle Indicators. With 3 faces at 90° separation, each face features a 163mm x 80mm graduated scale with 7mm legends for clear indication. The Rudder Position Signal can be either Analogue Voltage, derived from a Rudder Reference Unit mounted potentiometer or, via IEC61162-1 or -2 Serial Data using the $xxRSA sentence. Designed to be ceiling mounted (including VESA mount option) the unit is compliant with International Performance Standards including ISO 20673, IEC 60945, IEC 61162-1, IEC 61162-2 & IEC 62288. The NT1550 Panoramic RAI is the newest addition to Navitron’s comprehensive range of MED Type Approved Rudder Angle Indicators. With 3 faces at 90° separation, each face features a 163mm x 80mm graduated scale with 7mm legends for clear indication. The Rudder Position Signal can be either Analogue Voltage, derived from a Rudder Reference Unit mounted potentiometer or, via IEC61162-1 or -2 Serial Data using the $xxRSA sentence. Designed to be ceiling mounted (including VESA mount option) the unit is compliant with International Performance Standards including ISO 20673, IEC 60945, IEC 61162-1, IEC 61162-2 & IEC 62288. The case housing is constructed from robust ultra-light PET-G material designed to withstand the rigours of the marine environment. Product Features Include: 300mm Diameter Illuminated Scale and Pointer for Night Viewing Illumination Level Control by Integral Control, Remote Potentiometer or Control Voltage Signal Comprehensive Installation Set Up Facilities via the Integral 16 x 2 Alphanumeric LCD Display and associated Push Buttons
