Marine radar transponder
Racon

marine radar transponder
marine radar transponder
Add to favorites
Compare this product


Characteristics

Application domain
marine
Type
Racon

Description

Racon devices are used at sea to mark navigational hazards as RADAR targets for presentation on a ship navigational radar display. The word Racon comes from combining RAdar and beaCON. The McMurdo Marine Systems HEKLEO-SX Racon is a frequency agile all-weather radar transponder that works on both "X" band (3cm wavelength), and "S" Band (10cm wavelength) frequencies. A HEKLEO-SX Racon responds to a radar interrogation by transmitting a Morse code character which appears on the passing ships radar display. When HEKLEO-SX Racon receives a ships interrogating radar pulse, it responds with a return signal on the same Radar frequency, this results in a special Radar target image icon appearing on the ships radar display. The icon takes the form of a short line of dots and dashes forming a Morse character radiating away from the fixed position of the HEKLEO-SX Racon as indicated on the ships radar display. The length of the line usually corresponds to the equivalent of a few nautical miles on the display. Once the Morse letter is displayed on screen, the bearing and distance of the HEKLEO-SX Racon from the vessel can be observed. Even when numerous radar returns clutter the radar display, a coded Racon icon trace is an unmistakable feature on the radar display and provides the means for accurate and positive identification of a hazard to navigation.

Catalogs

No catalogs are available for this product.

See all of McMurdo‘s catalogs
