Boat navigation light 00347

for yachtLEDwhite

NAVISLIM vertical white 2 NM kit — port, starboard and stern navigation lights for vessels under 20 m. White housing, vertical mounting, compact and lightweight. Rated IP67 and certified WHEELMARK 60427/A0 MED. Regulated 10–30 VDC.

Key features

• Range: 2 nautical miles
• Vertical installation
• White housing (PC) with UV-treated ASA components
• IP67 waterproof rating
• Low power consumption (1.08 W)
• Does not interfere with AIS or VHF
• Compact dimensions and low weight (130 g)

Detailed description
NAVISLIM vertical white navigation lights are designed for pleasure and professional vessels under 20 m. The kit includes port, starboard and stern units with vertical mounting and a white cover for discreet installation. Light output provides a visible range of 2 NM while remaining compatible with onboard AIS and VHF communications. The units operate from a regulated 10–30 VDC supply, with very low current draw and durable materials (PC plus UV-treated ASA) for marine exposure. Certified to WHEELMARK 60427/A0 MED and compliant with EU Directive 2014/90/EU.Technical specificationsPower consumption: 1.08 WLuminous intensity: >5.4 cdSupply voltage: 10–30 VDC (regulated)Beam angle: 112.5°Materials: white PC + UV-treated ASALight colour: RedIngress protection: IP67Weight: 130 gDimensions: H 38 x L 85 x W 45 mmRange: 2 nautical milesWarranty: 2 yearsCertification: WHEELMARK 60427/A0 MED — compliant with EU 2014/90/EU
