Dispensing machine Single

Compact material unloader for highly viscous materials Robust and Dependable Dispensing: Both medium and high viscous materials are dispensed with a steady flow of material Limited amounts of maintenance increase production efficiencies for all users Performance-Enhancing Design: Unique system shape requires only one user for drum changes Lift system helps load drums and reduce the risk of operator injury 5-gallon model has minimal footprint for smaller production spaces Portability allows manufacturers to move system to multiple lines. Control Panel Operation: All operational features of the unit are located on one clearly marked panel Indicator lights alert users when material is running low and needs changing Increased Post Diameter: Ability to generate enough force to properly dispense materials over 3 million centipoise 55-GALLON Max Output: approximately 1.8 gal/min (6.8 L/min) Volumetric Displacement: 5.3 in^3/stroke Available Pump Ratio: 30:1 or 60:1 Max Air Input Pressure: 100 psi (7 bar) 5-GALLON Max Output: approximately 0.4 gal/min (1.5 L/min) Volumetric Displacement: 1.2 in^3/stroke Available Pump Ratio: 30:1 or 65:1 Max Air Input Pressure: 100 psi (7 bar)
