Outboard inflatable boat A240

rigidopenaluminum

Overview
ATLANTIS LITE series tenders are lightweight, compact rigid-hull inflatable boats designed for leisure use and as yacht tenders. The range offers ergonomic layouts, easy handling and a streamlined design. Four models are available: A240, A270, A300 and A330.

Available models

• A240
• A270
• A300
• A330

Standard features

• Aluminum V-shaped hull in marine-grade aluminium 5083 with powder coating RAL 9016 (white) and ENVIROX passivation treatment for aggressive marine environments and high temperatures
• GALA TABS – patented hull design providing transom expansion and reinforcement with transom brackets
• Internal aluminum and external plastic transom plates for engine installation
• Set of zinc anodes for additional corrosion protection
• Single-acting drain valve with membrane and stopper
• Non-slip deck coating for safe movement on board
• Three towing points and five lifting points
• Cast mooring eyebolt in the bow
• Bow and two stern handles in molded PVC
• Three-chamber U-shaped inflatable tube in PVC or Hypalon
• Overpressure valve
• Plugs for inflatable tubes in molded PVC
• Decorative covers for the tube with handles and logo
• Bottom beam with water deflector
• Bottom bar in molded PVC to protect the keel
• Mobile sliding aluminum seat
• Set of oars with oarlocks
• High-efficiency foot pump
• Repair kit and user manual

Optional equipment

• Alternative tube colours
• Alternative aluminium hull colour
• EVA marine deck as alternative deck coating
• Additional tube protection with molded PVC bottom bar
• Extra movable aluminum seat
• Soft cushion for the aluminum seat
• Storage bag under the aluminum seat
• Protective cover / parking awning
• Additional overpressure valves

Design & key elements
GALA TABS hull design improves performance by enabling rapid transition to planing and reducing fuel consumption. The boats include branded marine fittings, a bow footrest suitable for standing or securing a fuel tank, under-seat storage, advanced overpressure valves, sliding aluminium seating and an optional full cover for UV and weather protection.

Technical specifications

• A240
  LENGTH: 240 cm / 7’10" ft
  WIDTH: 152 cm / 5’0" ft
  WEIGHT: 40 kg
  TUBE: 38 cm
  CAPACITY: 2 pax / 300 kg
  ENGINE (recommended): 5 HP
  ENGINE (max): 6 HP
  ENGINE SHAFT LENGTH: 15"
  ALUMINIUM HULL THICKNESS: 2.5 mm
  BOAT CATEGORY: D
• A270
  LENGTH: 270 cm / 8’10" ft
  WIDTH: 152 cm / 5’0" ft
  WEIGHT: 44 kg
  TUBE: 38 cm
  CAPACITY: 3 pax / 350 kg
  ENGINE (recommended): 8 HP
  ENGINE (max): 10 HP
  ENGINE SHAFT LENGTH: 15"
  ALUMINIUM HULL THICKNESS: 2.5 mm
  BOAT CATEGORY: D
• A300
  LENGTH: 300 cm / 9’10" ft
  WIDTH: 162 cm / 5’4" ft
  WEIGHT: 50 kg
  TUBE: 42 cm
  CAPACITY: 4 pax / 400 kg
  ENGINE (recommended): 15 HP
  ENGINE (max): 20 HP
  ENGINE SHAFT LENGTH: 15"
  ALUMINIUM HULL THICKNESS: 2.5 mm
  BOAT CATEGORY: C
• A330
  LENGTH: 330 cm / 10’10" ft
  WIDTH: 162 cm / 5’4" ft
  WEIGHT: 56 kg
  TUBE: 42 cm
  CAPACITY: 4 pax / 500 kg
  ENGINE (recommended): 15 HP
  ENGINE (max): 20 HP
  ENGINE SHAFT LENGTH: 15"
  ALUMINIUM HULL THICKNESS: 2.5 mm
  BOAT CATEGORY: C
