Ship steering gear system hydraulic
Add to favorites
Compare this product
Characteristics
- Application domain
- for ships
- Operation
- hydraulic
Description
Fork-type hydraulic steering gear(single rudder)
1)Suitable for:
Containers, tankers, ferries, General cargo ships, passage ships, Dredgers and any other vessels that need more steering torque.
(2)Main Tech:
Max working torque: 15 KN.M — 250 KN.M
Max. mech. rudder angle: ± 45 degree
Time of rudder movement: ≤28 S
Rudder stock Diameter: 300mm — 900 mm
Working pressure: 13 Mpa — 20 Mpa
Design pressure: 16 Mpa — 24 Mpa
