Main Technical data
Length overall (incl. pulpit)16,18 m (53’ 1”)
Hull length (incl. platform)14,47 m (47’ 6”)
Beam max4,55 m (14’ 11”)
Draft (incl. props at full load)1,30 m (4’ 3”)
Displacement (at full load)22,3 t (49.163 lb)
Exterior styling & conceptNeo Design
Interior designerNeo Design
Hull designerAzimut-Benetti R&D Department
KeelV-shape with AFT deadrise 14.2°
Engines2 x Volvo IPS 800 - 600 mHP
Maximum speed (performance test mass)up to 35 kn
Cruising speed (performance test mass)up to 30 kn
Fuel capacity1440 l (380 US Gal)
Water capacity450 l (119 US Gal)
Azimut Yachts materials have been designed and developed to offer users the most accurate representation of the yacht possible.
The finish, standard equipment and range of optional on offer may vary from hull to hull.
The information provided by materials (Virtual Tours, Images, videos, etc…) is for information purposes only. While Azimut Yachts endeavours to provide accurate information on this site, some may still contain technical inaccuracies or typographical errors.
Azimut Yachts makes no representation or warranty as to the
