friction block / single / with becket / max. rope ø 8 mm
11603 Wichard

{{requestButtons}}

Characteristics

  • Type:

    friction

  • Number of sheaves:

    single

  • Configuration:

    with becket

  • Maximum line diameter:

    max. rope ø 8 mm

  • Application domain:

    for sailboats

  • Material:

    stainless steel

  • Working load:

    1,040 kg (2,292.8 lb)

  • Breaking load:

    2,300 kg (5,070.6 lb)

Description

MXEvo – DIA 6 mm – Captive pin – for max rope size 8 mm

MXEvo is the new generation of one-piece blocks developed by Wichard.
Thanks to the leash, this MXEvo version can’t loose its pin while opening, manipulating and closing the block. The pin is forged in high-resistant 17.4PH stainless steel.

Main MXEvo features:
> Dedicated to heavy load applications
> Impressive working and breaking load limits
> Captive pin on the standard version
> Becket function to make tackles
> Rope kept on track thanks to the fins
> Optimized weight and dimensions
> Easy opening – Easy rope installation
> Two versions existing in three sizes
> Limited rope wear thanks to the track conception
> Monobloc item (without mechanical part) for a better reliability
> For max rope size 8 mm
Applications
> 2:1 halyard purchase: mainsail, spinnaker, gennaker
> Flying sail furler terminals: tensioning at the top or from the bottom
Material
Grade 316L stainless steel
