Boat pump / transfer / seawater / centrifugal
PMTM08-70 Thermowell

Characteristics

  • Application domain:

    for boats

  • Applications:

    transfer

  • Fluid:

    seawater

  • Technology:

    centrifugal

  • Operation:

    electric

  • Flow rate:

    80 l/min (21.13 us gal/min), 30 l/min (7.93 us gal/min), 22.5 l/min (5.94 us gal/min), 15 l/min (3.96 us gal/min), 10 l/min (2.64 us gal/min)

Description

PMTM08 PMTM13 PMTM18 PMTM24 PMTM70
Condensing capacity [BTU/h] 8.000 13.000 18.000 24.000 70.000
Water flow [lt/min] 10 15 22,5 30 80
Power input [W] 27 45 60 115 270
Drawn current [A] 0,14 0,16 0,25 0,75 1,8
Power supply [V-Ph-Hz] 230-1-50 230-1-50 230-1-50 230-1-50 230-1-50
Suction / discharge diam. [mm] 14 17 20 20 26,5
Net weight [kg] 2 2,3 4 5,5 11
Sizes [mm] 167x104x100 202x106x113 272x120x130 250x132x153 393x135x166
