intervention underwater ROV
Cougar-XTi Saab Seaeye

{{requestButtons}}

Characteristics

  • Type:

    intervention

  • Depth:

    3,000 m (9842'06")

Description

The Seaeye Cougar-XTi is a 3000m depth rated version of the compact, highly flexible and extremely powerful Cougar-XT ROV system, which is aimed to address the industry’s need for a 3,000m observation ROV, capable of providing a "self help" capability and light work capability.

With all the benefits of the proven Cougar-XT and the full range of optional quick-change tool skids, the Cougar-XTi also features a new distributed control system and high frequency power supply system developed for deepwater operations. These new systems have been developed and used in Saab Underwater Systems’ military ROV systems.

Specifications
Depth rating 3000 msw
Length 1515 mm
Height 905 mm
Width 1000 mm
Launch weight 580 kg
Forward speed 3.2 knots
Thrust forward 170 kgf
Thrust lateral 120 kgf
Thrust vertical 110 kgf
Payload 80 kg
