Part no. 5101006600-xxx
Design According to rules of maritime classification societies and relevant standards
Housing Gear tray stainless steel 1.4404 (AISI 316L), powder coated RAL9017. Back side covered with PC hood, RAL9017
Reflectors 22°, 37°, 52°, 91° available
Safety pane Tempered glass, DIN 12150, clear
Cable entry IDC fast connection, 1x Cable Ø 9-14mm
Mounting Stainless steel brackets, adjustable
Protection class IP66/67
Weight 14 kg
Light source 6x LED engine
Wattage 6x 50 W
Equivalent 400 W HST/HIT
CCT (color) 5,000 K
Luminous flux 30,000 LM at Ta 20°C
Voltage 100-277 V AC
Frequency 50 - 60 Hz
