container ship cargo ship
CTE BEATRIZ Hijos de J. Barreras

{{requestButtons}}

Characteristics

  • Type:

    container ship

  • Length:

    159.8 m (524'03")

  • DWT:

    16,500,000 kg (36,376,273 lb)

Description

Main particulars:Length Overall: 159.80 m
Length between Perpendiculars: 143.00 m
Moulded Breadth: 24.80 m
Depth to Main Deck: 14.00 m
Maximum Draught: 9.50 m
Design Draught: 8.40 m
Deadweight at 9.50 m: 16500 T
Trial Speed: 18 knots
Crew: 20 people
Live-saving Appliances: 20 people
Range at Trial Speed (18 knots): 7000 miles
Classification:Lloyd’s Register: 100 A1 CONTAINER SHIP LI LMC, UMS, SCM, *IWS
Propulsion & Manoeuvring Equipment:Main Engine: 1 x 10395 kW at 500 rpm
Generating Sets: 3 x 1100 kW at 1500 rpm
Emergency Genset: 1 x 250 kW at 1500 rpm
1 x CP Main Propellers, 4 Blades, 5800 mm Diameter
2 x 478 kW CP Bow Tunnel Thrusters
Cargo Capacity:Holds ISO Cargo Capacity: 517 TEUS
ISO Cargo Capacity on Hatch Covers and Deck: 750 TEUS
EURO Cargo Capacity on Hatch Covers and Deck: 677 TEUS
Total ISO Holds and Deck: 1267 TEUS
Reefer Containers: 170
Tanks Capacity:Fuel Capacity (Fuel-oil): 947 m³
Fuel Capacity (Diesel-oil): 280 m³
Lub. Oil Capacity: 118 m³
