yacht davit / hydraulic / rotating / telescopic
WC SERIES 800 1000 Brower Systems Inc.

{{requestButtons}}

Characteristics

  • Application domain:

    for yachts

  • Operation:

    hydraulic

  • Type:

    rotating, telescopic

Description

Brower Systems is proud to announce an economic solution for launching your tender form the transom of your vessel. The Transom WC Series Davit is designed to be installed on vessels ranging from 45-65 feet in length. The boom can stow in a retracted position of 6 feet and can be hydraulically extended to 9 feet depending on your requirements, the extension can range in any position of extension for lifting the tender. The unique design of the this Transom Davit uses a power boom to raise and lower the tender and has the ability to extend or retract hydraulically to allow for launching the tender from the stern of the vessel. This compact and light weight davit uses a solid arm to connect to the tender that can be adapted to all applications. The davit is rotated manually and is designed to be mounted in a coaming or close to the transom bulkhead. Contact your Brower System sales representative for costing and availability. The Transom WC Series Davit has the following standard features that are part of the complete package and cost.Material is 6061 t6 Aluminum ExtrusionProof Test of 125 Percent Done at Time of AssemblyWireless Remote Pendant is Standard2-Function With Extension in/out and Boom up/Down12 0r 24 Volt d/c Hydraulic Power Unit Standard4.5” o.d. Standpipe is Provided as Standard With Receiver for the Base of Standpipe and Shear Transfer CollarPowder Coated FinishManual Rotation to 360 DegreesHydraulic Extension and Retraction With 6 Feet and Extends to 9 FeetEye Bolt Mounted on Boom to Allow Separate tie Down to Secure from SwingingStainless Steel Polished Boom CylinderPolished Stainless Steel Connection to Attach to Tender.
