Increased Power: 900 lumen & 13000 Lux
Protection Grade IP68
The internal lighting core is easely replaceable even with the hull in the water
Allowing easy upgrades of the LED technology or change in the color source
Thermal management included in the driver
Do not require remote stabilizer
Easy installation engineered product
Lenses specially treated against microorganisms
Low profile trim: for minimal water resistance
2-year Warranty on the material and 20.000 hours of functioning
|
|
|
|
|
|
|
The F-1 series offers a revolutionary new concept for underwater lighting for Super Yachts.
Achieving upto 25 degree hull angling within the fixture itself, it eliminates the need for massively long cofferdams, which improves Lamina flow and therefore fuel economy and ultimately speed whilst saving huge space inboard.
Being an LED powered unit (i.e. low maintenance) results in new thinking on yacht design. Old problems of access to 'traditional' underwater lights to change bulbs/service are now no longer as big a problem.
The F-1 Series is the most technically advanced underwater light every created. The unique 3 part delivery system offered by OceanLED ensures the very latest LED technology is utilized when the yacht is ready for launch.
Stage 1 - The Cofferdam assembly is delivered for the hot work (welding) to be completed.
Stage 2 - The electronics and cabling are supplied when needed.
Stage 3 - Light engine is delivered at the last stage to ensure the very latest LED technology is used.
The F-1 is currently being fitted to the latest new builds at the Feadship, Koninklijke De Vries Aalsmeer and Koninklijke De Vries Makkum facilities.
|
|
The OceanLED Puck Light fixture is designed to be used in Steel, Aluminium or Fibreglass hulls.
Cofferdams - We recommend tube for the Cofferdam walls to be sourced by the shipyard during installation to save on freight costs. OceanLED then supplies a Welding Back Plate which affixes to the tube creating the final Cofferdam for the light to be mounted.
Alternatively full cofferdams can be supplied.
For fibreglass hulls the follows along the same principal design where a molded pocket in the Fiberglass hull allows water to flow in and around the LED light enabling sufficient cooling.
If a General Arranagement (GA) can be supplied, our design department can assist in cofferdam design for maximum cost efficiency.
Full Cofferdams are available from us on request.
|
|
This underwater light with optic fiber provides a more powerful light than actual led-based lights.
This system gives you an unmatched quality of light games due to the powerful light source that allow to really create astonishing in water reflections.
Optical fiber is maintenance free, and life guaranteed.
|
|
Model S 1206: (Bronze) spotlight strong narrow beam
Will penetrate the water up to * 100 feet giving
a crisp detailed view of submarine life.
6 LED – 18 watt, 45 degrees beam, draw only
1.5 Amp at 12 volts, 750 Lumens at 9000 Kelvin.
Diameter 4 ½ (114 m/m) thickness 1” (25.4 m/m)
This model is supplied with external power regulator.
(12V/24V)
|
|
The Sea Vision SV10 model offers the largest aperture of all the fiberglass models giving maximum light output from the 150 watt metal halide lamp. It can be installed in the transom or the hull and is suitable for boats with 110-230 volt AC power, including sportfish, yachts and cruisers.
|
|
|
Underwater floodlights complete Yachtlite's extensive product palette for yachts. Yachtlite provides highest quality underwater floodlights with certification from a long-standing reputable manufacturer.
|
|
Model S 600: (Stainless Steel) flood wide angle illuminates up to * 30 feet around the transom area.
6 LED – 12 watt will draw only 1 Amp at 12 volts.
Large 100 degrees angle, 350 Lumens at 7200 Kelvin.
Diameter 3 1/8 (80 m/m) thickness 9/16 (15 m/m)
|
|
Model S 1515: (Bronze) Powerful 15 LED flood angle will illuminate up to * 100 feet.
15 LED – 36 watt, 90 degree beam angle.
Draw 3 Amp at 12 volts, 1610 Lumens at 8400 Kelvin.
Diameter 5 3/4 (146 MM) thickness 11/16 (27 MM)
The S 1515 is supplied with external power regulator
|
|
|
|
