boat windlass / vertical / hydraulic / single-drum
boat windlass
RC series

Working load: 350 kg - 1590 kg

... appropriate on larger boats, the RC12 Series represents the next generation of rope/chain windlass evolution in every respect. Every Maxwell automatic rope/chain windlass is available with all the necessary ...

See the other products
Maxwell Marine
boat windlass / vertical / electric / single-drum
boat windlass
VW series

Working load: 227 kg - 1590 kg

The VW10 evolved from the demand for a vertical windlass that could be used in a horizontally installed configuration but which would also, interactively handle a rope/chain rode. The traditional VW models could be used ...

See the other products
Maxwell Marine
boat windlass / vertical / electric / single-drum
boat windlass
VWC series

Working load: 850, 1590, 700, 1135 kg

The VWC Series is designed for automatic vertical handling of chain only anchor rodes while offering an independent capstan for the retrieval of a secondary rope and chain rode or to assist with docking procedures.

See the other products
Maxwell Marine
boat windlass / horizontal / hydraulic / single-drum
boat windlass
HRC FF series

Working load: 410 kg

The all new compact HRC FF are Maxwell’s horizontal versions of the latest innovative new vertical RC6 and RC8 automatic rope/chain windlasses. The new HRC FF are packed with original and proven features including patented rode management ...

See the other products
Maxwell Marine
yacht windlass / horizontal / electric / single-drum
yacht windlass
HRC10

Working load: 700, 850 kg

Maxwell’s all new HRC10 Horizontal Series represents yet another breakthrough in performance and anchor handling excellence. These horizontal, fully automatic rope/chain windlasses have been designed to meet the demands for use on larger ...

See the other products
Maxwell Marine
boat windlass / horizontal / electric / single-drum
boat windlass
Pro-Fish

Working load: 79 kg - 114 kg

Our Pro-Fish model is the ultimate windlass for fishermen. The Pro-Fish has an automatic freefall that allows you to pull right up over a wreck or ledge, and drop anchor with speed and precision. No more running your ...

See the other products
Lewmar
boat windlass / horizontal / electric / double-drum
boat windlass
H2

Working load: 163 kg - 243 kg

The stylish, horizontal H-Series Windlasses use the reliable worm gearbox technology. The integral contactor simplifies wiring and is protected by a durable maincase. The unit's waterproof seal requires minimum maintenance, and since ...

See the other products
Lewmar
boat windlass / horizontal / electric / double-drum
boat windlass
H3

Working load: 163 kg - 243 kg

The stylish, horizontal H-Series Windlasses use the reliable worm gearbox technology. The integral contactor simplifies wiring and is protected by a durable maincase. The unit's waterproof seal requires minimum maintenance, and since ...

See the other products
Lewmar
boat windlass / horizontal / electric / single-drum
boat windlass
Pro-Series

Working load: 79 kg - 114 kg

Praised by professionals worldwide, the horizontal Pro-Series is a shining example of Lewmar's commitment to provide quality products for boats from 6m-11.5m (20-38ft). It's DIY-ready, easy to install and housed in 100% 316 stainless ...

See the other products
Lewmar
boat windlass / horizontal / electric / single-drum
boat windlass
Pro-Sport

Working load: 63 kg

Lewmar’s Pro-Sport windlass is designed as an economical package for rope and chain applications, without compromise to quality or performance. Pro-Sport is designed around a highly efficient spur gearbox, using smaller, ...

See the other products
Lewmar
boat windlass / vertical / electric / single-drum
boat windlass
Barracuda 900 - B912

Working load: 220 kg

... models take up less space on the deck. Designed for smooth & silent motor/gear operation under the deck. Powerful and compact windlass with capstan for optional warping operation. Vertical shaft in stainless steel. Highspeed ...

See the other products
Anchorlift
boat windlass / vertical / electric / single-drum
boat windlass
Barracuda 600 - B612

Working load: 180 kg

... models take up less space on the deck. Designed for smooth & silent motor/gear operation under the deck. Powerful and compact windlass with capstan for optional warping operation. Vertical shaft in stainless steel. Highspeed ...

See the other products
Anchorlift
boat windlass / vertical / electric / single-drum
boat windlass
Dolphin 1000

Working load: 250 kg

... Profile models are designed for smooth & silent motor/gear operation under the deck and take up less deck space. Powerful windlass with a new compact motor.Vertical shaft in stainless steel. Highspeed drop of up to 40 ...

See the other products
Anchorlift
boat windlass / vertical / electric / single-drum
boat windlass
Mako M1212 / M1512 / M1524

Working load: 485, 400 kg

M1512-10 Anchorlift™ Mako 1500 Low Profile Windlass: 1500 watt, 12 volt, 5/16" HT G43 Chain - 5/8" Rope Gypsy Motor: 1500w, 12v Max Working Load: 485kg / 1067lbs. Max Power Pull: 1185kg / 2607lbs. Speed Down: ...

See the other products
Anchorlift
boat windlass / horizontal / electric / single-drum
boat windlass
Mako M1212C / M1512C / M1524C

Working load: 400, 485 kg

... 1500 watt motors, ideal for 40-60 foot boats. Designed for smooth & silent motor/gear operation under the deck. Powerful windlass with capstan for optional warping operation. Vertical shaft in stainless steel. Highspeed ...

See the other products
Anchorlift
sailing superyacht windlass / for ships / horizontal / electric
sailing superyacht windlass
YMV-WW/

Working load: 1 t - 50 t

YMV Anchor windlass winches are custom build according to operational requirements. Main Properties: -Pull capacity: 1- 50 t -Suitable Chain Diameter: 12 - 81 mm -Manual operated clutch and band brake Optional: -Cable ...

boat windlass / vertical / electric / single-drum
boat windlass
SMART-R1

Working load: 390, 270, 300 kg

Aluminum and stainless steel vertical windlass with round base. Available in high or low profile, with different drives and recommended for boats up to 13mt. SMART-R1 can use the 6mm, 7mm or 8mm chains. Comes with built-in ...

See the other products
Italwinch
boat windlass / vertical / electric / single-drum
boat windlass
SMART-R3

Working load: 390 kg - 1700 kg

Aluminum and stainless steel vertical windlass with round base. Available in high or low profile, with different drives and recommended for boats up to 16mt. SMART-R3 can use the 6mm, 8mm, 10mm or 10mm DIN766 chains. ...

See the other products
Italwinch
boat windlass / vertical / electric / single-drum
boat windlass
STAR

Working load: 1250, 1650, 1700, 1750 kg

STAR is a stainless steel AISI 316 vertical windlass. Available in high or low profile, with different drives and recommended for boats up to 19m. STAR can use chains from 10 mm to 12 mm and comes with built-in chain ...

See the other products
Italwinch
yacht windlass / vertical / electric / single-drum
yacht windlass
MOON

Working load: 3400, 3500 kg

MOON is a stainless steel AISI 316 vertical windlass. Available in high or low profile, with different drives and recommended for boats up to 30m. MOON can use chains from 12 mm to 14 mm stud link and comes with built-in ...

See the other products
Italwinch
boat windlass / horizontal / electric / single-drum
boat windlass
Giglio

Working load: 400 kg

Giglio manual windlass has a double effect drive system. It comes with aluminium gear box white painted and independent anodized aluminium drum and chromed bronze gypsy.

See the other products
Italwinch
yacht windlass / vertical / electric / single-drum
yacht windlass

Working load: 1 kg

boat windlass / vertical / hydraulic / double-drum
boat windlass

Anchor windlass with one or two wildcats with clutch and ribbon brake for diverse type and size of chains, driven by means of hydraulic motor

boat windlass / horizontal / electric / single-drum
boat windlass
BALDER BL3 XY

Working load: 50 kg - 540 kg

Horizontal windlasses Maximum flexibility of installation AISI 316 Stainless steel and chromed bronze Integrated sensor and magnet for chain counter Rope and chain on a single gypsy Automatic system of anchor-rode ...

See the other products
Quick
boat windlass / vertical / electric / single-drum
boat windlass
Prince - DP1

Working load: 40 kg - 220 kg

Vertical windlassesStainless steel Aisi 316 baseWith and without drumManual Free-Fall systemSupplied with pressure leverInspection coverWatertight motorAnodized aluminium gearbox

See the other products
Quick
boat windlass / vertical / electric / single-drum
boat windlass
FC.0X0.211XX series

Working load: max 115.0 kg

... retrieved with the chain of the all chain anchor rode still in the windlass. Every windlass comes with most of the required components needed for installation. A base gasket seal between the windlass ...

boat windlass / vertical / electric / single-drum
boat windlass
FC.0X0.221XX series

Working load: max 145.0 kg

... retrieved with the chain of the all chain anchor rode still in the windlass. Every windlass comes with most of the required components needed for installation. A base gasket seal between the windlass ...

ship windlass / horizontal / hydraulic / single-drum
ship windlass
AWHV-14-WH

Working load: 1636 kg

Application: Single chainlifter, hydraulic anchor windlass Features: • Handwheel applied / released drum band brake • Planetary drive with failsafe brake • Heavy duty manual band brake and clutch • Warping head • Designed ...

See the other products
Hawboldt Industries
ship windlass / horizontal / hydraulic / single-drum
ship windlass
AWHV-16-WH

Working load: 1636 kg

Application: Single chainlifter, hydraulic anchor windlass Features: • Handwheel applied / released drum band brake • Planetary drive with failsafe brake • Heavy duty manual band brake and clutch • Warping head • Designed ...

See the other products
Hawboldt Industries
boat windlass / vertical / electric / single-drum
boat windlass
Storm VRC 850

Working load: 96 kg

• Polished stainless steel components. • Rope chain combination gypsy for rope and chain combination or chain only • Rope Chain Management System (RCMS) • Quick release integrated swivel chain pipe cover • Gypsy with low profile clutch ...

See the other products
Muir Windlasses
boat windlass / vertical / electric / single-drum
boat windlass
Storm VR/VRC 1250

Working load: 125 kg

• Polished stainless steel components • Rope chain combination gypsy for rope and chain combination or chain only • Rope Chain Management System (RCMS) • Quick release integrated swivel chain pipe cover • Gypsy with low profile clutch ...

See the other products
Muir Windlasses
boat windlass / vertical / electric / single-drum
boat windlass
X1

Working load: 80, 120, 70 kg

Main Features Luxury chrome bronze base and drum With drum or Low profile Indepent Gypsy and drum operation Rope and chain combination Gypsy Manual chain release Rope chain management by the spring loaded ...

See the other products
Lofrans
boat windlass / vertical / electric / single-drum
boat windlass
X2

Working load: 80, 165, 190 kg

Main Features Luxury chrome broze base and drum Special watertight stainless steel ball bearing in the base With drum or Low profile Indepent Gypsy and drum operation Rope and chain combinaton Gypsy Manual ...

See the other products
Lofrans
ship windlass / horizontal / electric / single-drum
ship windlass
AHAW

Horizontal Anchor Windlass: Model AHAW Features: - Electric or hydraulic power - Variety of control options - Failsafe drive train braking system - AISI 316 stainless fasteners (3/4” dia. & smaller) - Zinc-plated ...

ship windlass / vertical / hydraulic / single-drum
ship windlass
AVAW

Vertical Anchor Windlass: Model AVAW Features: - Electric or hydraulic power - Variety of control options - Failsafe drive train braking system - AISI 316 stainless fasteners (3/4” dia. & smaller) - Zinc-plated ...

boat windlass / horizontal / electric / single-drum
boat windlass
DZC 401 E

Working load: 390, 590 kg

DZC 401E is the smallest windlass in horizontal range. It is driven by a 1200W (12 or 24VDC) electric motor providing a max. pull of 590 kgs. It has a gypsy for chains 8 or 10 mm DIN766.

See the other products
Data Hidrolik Makina Sanayi
boat windlass / horizontal / electric / hydraulic
boat windlass
DZC 901/902

Working load: 660, 730, 1100, 1000 kg

DZC 901 and 902 are horizontal anchor windlasses with single or double gypsies. Electric or hydraulic versions are available providing a max. pull of 1100 kgs. It has a gypsy for chains 10, 12 or 13 mm DIN766, 11 or 12.5 mm stud-link.

See the other products
Data Hidrolik Makina Sanayi
boat windlass / horizontal / electric / single-drum
boat windlass
PRO 710 Series

Working load: 120 kg

710 series suit boats from 4.5~6m(15~20 ft) or handle up to 6.8kg(15lb) of anchor The 710 series are specially designed for smaller size boats, with a compact, easy operating and easy to install by yourself. The durable nylon or stainless ...

See the other products
South Pacific Industrial
boat windlass / horizontal / electric / single-drum
boat windlass
PRO 800 Series

Working load: 300 kg

800 series suit boats from 6~9m(20~30ft) or handle up to 13.6kg(30lb) of anchor The 800 series have been developed with up-to-date technology and ideals, with efficient spur gears instead of traditional worm gears which can reduce ...

See the other products
South Pacific Industrial
hydraulic windlass / for boats / horizontal / single-drum
hydraulic windlass
LP Cat

Working load: 1 kg

Used as a hauling or lifting device for hoisting equipment or fish from the hold. May be mounted on spool frame. Aluminum Capstan Steel Frame Construction Hydraulic Motor Epoxy Paint

hydraulic windlass / for ships / horizontal / double anchor
hydraulic windlass

Working load: 14000 kg

Anchor Windlasses and Winches Rapp Marine produces anchor winches and windlasses for handling anchors of many shapes and sizes Features for a Rapp Marine anchor winches and windlasses include: - Up to 105 mm (4.13 in) Grade 1-3 ...

ship windlass / horizontal / hydraulic / single-drum
ship windlass
WYS-60 : 30T-110T

Working load: 150, 255 lb

The WYS-60 is a high-performance hydraulic anchor handling system that includes HPU, remote control interface, and five-pocket wildcat for 3.75" (95mm) stud-link anchor chain. Rugged construction, extreme pulling and braking power, and ...

hydraulic windlass / for ships / horizontal / single-drum
hydraulic windlass

Working load: 1 kg

Horizontal anchor windlasses from 22 up to 120 mm Vertical anchor windlasses from 22 up to 56 mm The windlasses can be: - single/double chain wheel type - single/double mooring drum type The windlasses can be equipped with ...

See the other products
C.M.T
electric windlass / for ships / horizontal / single-drum
electric windlass

Working load: 1 kg

Horizontal anchor windlasses from 22 up to 120 mm Vertical anchor windlasses from 22 up to 56 mm The windlasses can be: - single/double chain wheel type - single/double mooring drum type The windlasses can be equipped with ...

See the other products
C.M.T
ship windlass / horizontal / hydraulic / electric
ship windlass

... sizes, along with options like manual and hydraulic brakes, jaw clutches, gypsy heads and chain stoppers. Combination winch/windlass units are also available. Double Wildcat Several Chain Sizes Available ...

See the other products
Schoellhorn-Albrecht Machine Company
ship windlass / horizontal / hydraulic / electric
ship windlass

... sizes, along with options like manual and hydraulic brakes, jaw clutches, gypsy heads and chain stoppers. Combination winch/windlass units are also available. Single Wildcat Several Chain Sizes Available ...

See the other products
Schoellhorn-Albrecht Machine Company

How to choose this product

windlass

A windlass consists of a motor turning a drum and/or a wildcat, or gypsy. It is used to handle anchor and mooring lines.

Applications

NauticExpo offers large, powerful models for ships and commercial vessels, as well as smaller, more attractive versions for recreational and leisure craft.

Technologies

Most windlasses on recreational craft are electric or hydraulic, while ships models are sometimes powered by a pneumatic or internal combustion engine. The motor drives two main parts, the wildcat and the warping-end. The former is a notched wheel that engages the chain links. The latter handles lines.

When the chain and anchor are particularly heavy, the windlass has a stopper in order to keep the chain from slipping when the wildcat is engaged. Most wildcats have a clutch which can be released to let the chain run free while anchoring.

While the rotating drum is usually horizontal, vertical models exist. The motor is often mounted below the deck, especially on leisure vessels. Operation is from a panel or a hand-held device, either wired or a remote control. Double windlasses can handle two mooring lines.

How to choose

Chain diameter and anchor weight must be considered when selecting a windlass. Whether horizontal or vertical, configuration should ensure that the chain or line falls into the stowage locker without encountering obstacles or sharp angles.

Advantages

- Facilitates handling chain and line

Disadvantages

- Occupies space in the forecastle
- Significant power consumption
