The D60 Solo water maker (60 l/h - 230V) can be powered by a very small power generator, a converter or a 230V alternator. It consumes 3 Amps.
And now also: The D100 SOLO, consuming 5A. |
|
The HP V series answers to the demands of spaces on board with regards to the mono block construction.
The vertical conception of the plant gives the possibility to insert the system in tight places. The base of the HP V is only 470 mm X 280 mm, and the height is 620 mm.
These measurements are referred to the body of the watermaker that in this case does not include the membranes that can be easily be installed vertically or horizontally everywhere. The watermakers of the V series are modular and can be supplied in the V KIT version (see the drawing in the following page ) without any extra cost.
|
|
HP SC DOUBLE is supplied in a single block. It is a modular system composed by two independent machines, producing from 140 lt/h with two membranes 2540 up to 540 lt/h with 8 membranes.
The machine can be supplied in a MANUAL version, the AUTO version (with automatic membranes' flush) and eventually equipped with RP TRONIC system, the automatic pressure regulation.
|
|
HP SC ( Super Compact) is supplied on its frame. SC Series can be equipped of membranes 2521 (short) up to a production of 140 Lt/h and can produce up to 260 Lt/h with four membranes 2540.
SC Auto series is equipped of the automatic pressure regulation and automatic membranes flushing.
|
|
PLASTIMO AQUA-BASE WATERMAKERS
Plastimo Aqua-Base watermakers come in a large range to cover all navigation programs. They operate either from 12 and 24 Volt DC board batteries or from 220 Volt generators.
Water production ranges from 30 to 240 litres/hour.
• Optimum quality
All models feature highly reliable components, tested and approved to ensure a total peaceful mind when sailing. The high pressure pumps with 3 ceramic pistons are corrosion resistant. The filtering diaphragms can bear pressures several times higher than operation pressures. The chassis is engineered from 316 L stainless steel.
Construction complies with ISO 9001 standards; every model, whatever the size, is tested before shipment.
• Simple and convenient installation
The water maker is supplied either in kit or on a frame, to suit your installation requirements. Its components are designed to produce absolute minimum vibrations (further absorbed by rubber pads
under the plate). The watermaker can be used at night or when
the team is resting. |
|
Seatec Marine Technologies
manufactures a comprehensive range desalination plants, both "containerized" not The containerized systems are built of metal shipping containers and assembled and fully tested at our before being delivered, with no need on-site system assembly, pipe work, electric wiring or mounting of components. The complete system includes a pretrends phase of the sea water (filtration and chemical addition), pumping equipment, membranes, and a post treatment permeate. Our units are designed to pump up to 500 m3/Day potable water seawater. |
|
D 30 to D 60 : 12/24 Volts, 370 W -
D 100 : 12/24 Volts, 600 W
If the boat does not have an A.C. generator, the 12/24V models will be suitable.
|
|
The DUO is the first bi-powered water maker system world-wide.
It functions at the turn of a switch either on D.C. (12 or 24V) or on A.C. (120, 230 or 400V), as the DUO is an intelligent patented system.
Thanks to this system, the motors operate independently from each other, with neither electric clutch activation nor manual manipulation of the pulleys.
Like all Dessalator products the DUO is 100% reliable and safe. For over six years major shipyards have been including it as a standard fixture and since 2005 the DUO 100® has become indispensable for navigators.
The advantage of the DUO is its "2 in 1" aspect, as if there were two water makers available with the facility to function optimally and logically. |
|
Ultra Compact watermaker with TERS
(Thermal Energy Recovery System).
It can be supplied in 12V - 24V - 220V 50Hz - 230V 60 Hz
|
|
Ultra Compact watermaker with TERS
(Thermal Energy Recovery System).
It can be supplied in 12V - 24V - 220V 50Hz - 230V 60 Hz
|
|
| If you need more water and if you have a real 6 KW, this range of 90, 160, 200 and 280 litres / hour will fit your requirement of fresh water. |
|
| If you need more water and if you have a real 6 KW, this range of 90, 160, 200 and 280 litres / hour will fit your requirement of fresh water. |
|
D 440 Model:
Total power: 5,5 KW
- For industrial equipment
- Double stainless steel pre filter multi-cartridges
- Equipped with bronze pump with rinsing valve
- Carbon cased membrane |
|
The most widely-used emergency desalinator
• Produces up to 4.5 litres per hour
• Produces enough water for multiple person liferafts
Widely used by US and international military forces, voyagers, sea kayakers, and other adventurers
|
|
| "Compact" serie includes different reverse osmosis models assembled in a stainless steel frame along with all the technical features and the qualiy that Tecnicomar watermakers have always had. The seven models of "Compact" watermakers have a fresh water production from 35 up to 220 liters per hour. |
|
| "Modular" is a line of Reverse Osmosis watermakers designed for small boats. Thanks to the reduced dimensions "Modular" can be easily installed even when room on board is small. The unit is fitted on a stainless steel frame in a way that all the components can be easily inspected and maintained. The stainless steel frame can be easily removed to allow the separate installation of the control box and the high pressure pump. |
|
High Production Reverse Osmosis Desalinator
Watermakers with high flow rate. Effective fresh water flow rate from 220 till 300 litres/hour.
Compact Special models are provided with prefilters fitted into the frame and with automatic pressure regulation system as standard equipment. |
|
- The PowerSurvivor-40E delivers 5.7 litres per hour. It is the only power watermaker that converts to manual operation in emergencies.
- No watermaker draws so few amps. Using only 4 amps, the 40E can run for extended periods on alternative power alone. |
|
| The "STDC SY" serie is designed for the production of high quantity of fresh water on board, like in Super Yachts or cruising boats and merchant vessels. Standard Automatic pressure regulation. Six different models are available with a fresh water production from 400 to 1450 liters/hour -on demand even over-. The watermakers are on a solid stainless steel frame including all the system components, and also an automatic membranes flushing system and the backwashable multimedia sand filter. |
|
HIGH PRODUCTION REVERSE OSMOSIS WATERMAKERS
Bicompact consists of two Reverse Osmosis watermakers which can run in parallel or in stand-by. This is useful when you need to make the maintenance in one of the two watermakers. Total fresh water production from 440 up to 600 liters/hour. Simple maintenance thanks to the overturnable system of the membranes set. |
|
| ... products without information |
| |
|
|
