The Webasto Water Station acts as a central unit for the heating of the vessel’s warm water heating system (such as radiators & fan heat exchangers). Additionally, domestic warm water is heated on demand using a Webasto Calorifier. The switching from central heating to domestic warm water heating is done automatically.
The Webasto Calorifier quickly and efficiently heats the domestic warm water by a separate coil from the engine and a coil from the Webasto water heater circuit. The additional electrical 230 V immersion heater
ensures the provision of domestic warm water at shore connection.
|
|
The compact dimensions and capacity of the 16 litres 316 stainless tank satisfies a large part of the market. The BX16 is easy to install and highly
functional. On request it is available with the heat exchanger only (without electric element).
|
|
The Nautic Boilers are the result of Quick's long experience. Since 1998 Quick has been producing water heaters for boats, in its Nautic Boiler BX series.
The B3 project was devised from the need to create a quality line, competitive on all markets. The B3 Boilers are the simplest and safest answer to guarantee hot water on board without any type of problem, also thanks to the quality of the materials and structure. The container is in composite material and the tank is in AISI 316 stainless steel. The B3 Nautic Boilers are produced in versions of 15, 20, 25, 30 and 40 litres and are guaranteed for 3 years.
|
|
- High quality materials
- Heat exchanger with wide exchange surface
- Produces hot water from the electric element, that Is fitted with an adjustable safety thermostat.
- Relief / non-return vale that allows discharging of the water heater in case of disuse
|
|
|
The BXS water heater range is distinguished by the square-shape design, making for particularly easy installation.
|
|
"With a QL water heater you really have a more comfortable life on board. A QL water heater quickly and easily provides enough water at the right temperature for a shower, washing up, shaving etc. The water in a QL water heater is heated by the energy released from the engine cooling system. Use is thus made of the heat that would otherwise go to waste. The water heater also has an immersion heater for connection to on-shore po-wer. An adjustable thermostat cuts off heating at the desired temperature. It has a heater cut-out to prevent boiling.
The water heater is available in 20, 30, 40 and 60 L (5-16 gallons) sizes. The tank is made completely in acid resistant stainless steel, which makes it very suit-able for the marine environment. The 1.5 mm thickness and TIG welded joints make the tank very strong and give in-creased corrosion protection. The design and materials also meet the highest sani-tary requirements.
The QL water heater is easily mounted, vertically or horizontally, with stainless steel brackets. To obtain maximum ef-fect the outlet is uppermost, whether installed vertically or horizontally. As an optional extra, a thermostatic mixer is available which reduces hot water con-sumption and protects against scalding."
|
|
Indel Marine has intruduced a slim line, box style water heater to its range, which has been designed for easy installation in narrow spaces om board. The Isotemp Slim Square has a 16 litres capacity, quick and effectively heats water up via the boat engine or by the electrical heater element if the boat is connected to shore power. The water is heated to above 70°C which enables water to be heated on board at the correct levels from both hygiene and safety purpose.
It can be installed in a varity of position, making it more vesatile than standard models currently available. As with all Isotemp water heaters, the Isotemp Slim square has been constructed with a robust acid proof stainless steel (AISIS 316) and fitted with special components to protect it from overheating. All electrical installations are fatory made and delivered with a cable and plug.
It also features a safety valve for 5.5 bars with a built-in two-way check valve, which reduces or prevents spill water by expansion. It also has a winter drain function. Thermostat mixing valve can be mounted as an option.
The safety valve is set to 5.5 bar/80 psi on this model
|
|
Isotemp Slim is a range of water heaters, available in three sizes, 15, 20 and 25 litres. Isotemp Slim has an exlusive look and design, with brushed stainless steel cover. The highest capacity is achieved by the engine water heat exchanger, as well as by the immersion heater mounting. They are positioned as low as possible inside the tank to heat the water where it is coldest.
|
|
Isotemp Basic has an exlusive look, with its brushed stainless steel cover, but most important is the internal design. The highest capacity is achieved by the engine water heat exchanger as well as the immersion heater placement. They are positioned in the lowest part of the tank where the water is coldest, to really heat all the water in the tank, which grants an outstanding volume of hot water. The water in- and outlets are also designed for a minimal mixing of cold water into thee hot, by the incoming water. The selected materials are all the best; tank, tubes and all materials in contact with the water are made of acid proof stainless steel AISI 316 and welded with protection gas to eliminate any risk of corrosion. Each water heater is individually leakage tested to 16 bar/230 psi, before delivery.
|
|
Hot water - everywhere and at any time, from the cooling system of the boat engine. The RHINE STREAM boiler offer to you with smallest energy employment greatest possible comfort. They supply while driving constantly hot water to you with and regard it warm after trip end "to typical as RHINE STREAM "over 24 hours.
Execution: Maintenance-free, particularly thick-walled, printingexamined cu tank in seven, the needs and possibilities adapted sizes. By unusually good isolation it is possible to operate the plant also very economically over an additionally available electric heating (1.0 KW up to 3.0 KW). This cartridge is naturally provided with overheating protection (land connection power supply generator). In the chilled water zone of the boiler inserted relief valve TÜV is examined.
Operational area: With boats with liquid-cooled engines the boiler is integrated into the cooling system. The heating-up time of the memory depends on the achievement of the boat engine and the conduit lengths. The installation is owing to that well thought out construction completely problem-free. A drilling template is attached to each equipment. We supply boilers starting from a size of 15 liters in lying execution. The fastening parts of this water heater are swivelling and adjustable, so that a problem-free ground, wall and a ceiling mounting result.
|
|
Provides constant pressure water supply to Carbonators, Ice Makers, Non-carbonated drink dispensing valves, Coffee/tea brewers, FCB/frozen drink machines, Moist-heat food holding cabinets.
|
|
| ... products without information |
| |
| ... products without information |
| |
| ... products without information |
| |
Provides constant pressure water supply to Carbonators, Ice Makers, Non-carbonated drink dispensing valves, Coffee/tea brewers, FCB/frozen drink machines, Moist-heat food holding cabinets.
|
|
|
|
