The Flush Mount from OceanLED has an exceptionally low profile giving it virtually unlimited Hull Mounting options. This light can be retro-fitted into most existing underwater lighting hole cut outs, offering immediate benefits of no Startup power surge, low heat, minimal maintenance and improved light output.
Suitable for Fiberglass, GRP and wooden hulls and now also for use on aluminium/steel hulls using the delrin sleeve.
Low profile bezel offering almost unlimited mounting possibilities.
Lloyds Type Approved, RINA, ABS Type Approved, USCG Ignition Protected and ABYC H-27 Side Load approved.
All lights utilize Tritonium Optical lenses, and are supplied with a quick connect system by Deutsch ensuring almost 'fool proof' installation and compliance with ABYC, E11 regulations.
Available in 1520, 2010 & 3010 Series with Super White LEDs, Super Blue LEDs and the Super Green LEDs.
|
|
The original Thru-Hull with the worlds smallest hole cut-out for a thru hull light at only 1"! This light with a 30mm profile head makes it ideal for Transom mount applications. A very quick to fit and effective underwater light.
Suitable for Fiberglass, GRP and wooden hulls and now also available for use on aluminium/steel hulls using the delrin sleeve.
Lloyds Type Approved, RINA, ABS Type Approved, USCG Ignition Protected and ABYC H-27 Side Load approved.
All lights utilize Tritonium Optical lenses, and are supplied with a quick connect system by Deutsch ensuring almost 'fool proof' installation and compliance with ABYC, E11 regulations.
Available in 1010, 1520, 2010 & 3010 Series with Super White LEDs, Super Blue LEDs and the Super Green LEDs.
|
|
The most powerful underwater light available is from OceanLED - the NEW 4010 Super Nova lives up to its name.
At twice the power of a 3010, the 4010 Super Nova is a hybride of the ever popular 1" Thru Hull. Utilizing a slightly larger hole cut out at 1 1/2" the 4010 Super Nova offers the largest light output of any underwater light available on the market, and is a landmark in LED technology.
If you want the best and the biggest underwater light - then the 4010 Super Nova is it.
Suitable for Fiberglass, GRP and wooden hulls and also for use on aluminium/steel hulls using the delrin sleeve.
All lights utilize Tritonium Optical lenses, and are supplied with a quick connect system by Deutsch ensuring almost 'fool proof' installation and compliance with ABYC, E11 regulations.
Available with Super White LEDs, Super Blue LEDs and the Super Green LEDs.
Currently under going full Lloyds Type Approval.
|
|
|
|
|
|
|
The HID Thru-Hull SeaLite® is an extremely rugged system with unmatched light output. The fully sealed light head, scratch resistant sapphire port and precision-machined housing ensure that the system will remain reliable, even in the harshest environments. Each version utilizes the same thru-hull fitting and lamp, but offers ballast options to suit various installations and budgets.
The HID-X is the fully outfitted version of the 150W HID that includes automatic thermal and moisture sensors and integrated fault lights. This unit comes standard with a 15-foot interconnect cable and 15-foot power cable.
The HID-S version is very similar to the HID-X except that it does not include the sensors and, therefore, utilizes a smaller housing for the ballast. This unit comes standard with a 15-foot interconnect cable and 15-foot power cable.
The HID-O is our OEM version intended for boat manufacturers that want to incorporate the unit into a boat design. This unit includes the ballast (without splash-proof enclosure box) and a 15-foot interconnect cable (no power cable).
All versions are available in a stainless steel fitting or an optional titanium/stainless steel fitting for superior corrosion resistance in seawater. Thru-Hull SeaLites® - whiter, brighter and more durable.
|
|
Increased Power: 900 lumen & 13000 Lux
Protection Grade IP68
The internal lighting core is easely replaceable even with the hull in the water
Allowing easy upgrades of the LED technology or change in the color source
Thermal management included in the driver
Do not require remote stabilizer
Easy installation engineered product
Lenses specially treated against microorganisms
Low profile trim: for minimal water resistance
2-year Warranty on the material and 20.000 hours of functioning
|
|
The OceanLED Puck Light fixture is designed to be used in Steel, Aluminium or Fibreglass hulls.
Cofferdams - We recommend tube for the Cofferdam walls to be sourced by the shipyard during installation to save on freight costs. OceanLED then supplies a Welding Back Plate which affixes to the tube creating the final Cofferdam for the light to be mounted.
Alternatively full cofferdams can be supplied.
For fibreglass hulls the follows along the same principal design where a molded pocket in the Fiberglass hull allows water to flow in and around the LED light enabling sufficient cooling.
If a General Arranagement (GA) can be supplied, our design department can assist in cofferdam design for maximum cost efficiency.
Full Cofferdams are available from us on request.
|
|
|
|
|
|
|
The F-1 series offers a revolutionary new concept for underwater lighting for Super Yachts.
Achieving upto 25 degree hull angling within the fixture itself, it eliminates the need for massively long cofferdams, which improves Lamina flow and therefore fuel economy and ultimately speed whilst saving huge space inboard.
Being an LED powered unit (i.e. low maintenance) results in new thinking on yacht design. Old problems of access to 'traditional' underwater lights to change bulbs/service are now no longer as big a problem.
The F-1 Series is the most technically advanced underwater light every created. The unique 3 part delivery system offered by OceanLED ensures the very latest LED technology is utilized when the yacht is ready for launch.
Stage 1 - The Cofferdam assembly is delivered for the hot work (welding) to be completed.
Stage 2 - The electronics and cabling are supplied when needed.
Stage 3 - Light engine is delivered at the last stage to ensure the very latest LED technology is used.
The F-1 is currently being fitted to the latest new builds at the Feadship, Koninklijke De Vries Aalsmeer and Koninklijke De Vries Makkum facilities.
|
|
This underwater light with optic fiber provides a more powerful light than actual led-based lights.
This system gives you an unmatched quality of light games due to the powerful light source that allow to really create astonishing in water reflections.
Optical fiber is maintenance free, and life guaranteed.
|
|
|
Underwater lightning, located, for example, on a boat's underbelly, implies various difficulties if created using conventional systems. In fact, these require getting close to the hull, and performing maintenance or making replacements in hard to reach areas. These problems do not occur with optical fibres lightning.
|
|
1W Single chip, 316 stainless steel, fixed low voltage LED fittings
IP68 Rated screw threaded body with silicon seals and hexagonal lock-nut allows fitting in underwater environments.
Mounting surface thickness - Min. 2mm, Max. 12mm
NON-REPLACEABLE white LED life of up to 30,000 hours (Due to the nature of LED's a slight colour variation from lamp to lamp is possible)
Submersible to a depth of 1m
Fitted with 1m of cable for connection to a 350mA Constant Current LED driver (N.B. to be wired in SERIES)
Maximum 9pcs connected to a 9W Constant Current LED controller
Cool operating temperature
Available in stainless steel finish
Dimmable with AU-LEDD16CC driver and AU-DSPLED dimmer unit
|
|
|
|
|
|
|
For decades DeepSea Power & Light has been designing innovative underwater products that exceed industry standards. The new 18 LED Thru-Hull SeaLite® is the next evolution of the proven Thru-Hull SeaLite® design.
Several features come together in the 18 LED Thru-Hull SeaLite® to create a light that offers amazing light output, is extremely rugged and most importantly, safe. There are 18 high color temperature LEDs, each with its own reflector to distribute the light for maximum effect. Thermal compensation circuitry regulates the temperature of the LEDs, improving the life of the LEDs and allowing the light to be run in air. The 316 stainless steel housing has two double seals, ensuring that the 18 LED Thru-Hull SeaLite® will remain watertight, even in the harshest environments. To simplify installation, the driver board is integrated into the watertight housing. The 18 LED Thru-Hull SeaLite® is even serviceable from inside the boat. And, with an ultra long life, the 18 LED Thru-Hull SeaLite® requires no bulb maintenance!
The 18 LED Thru-Hull SeaLite® provides the peace of mind in knowing that it was designed by a company with over 20 years expertise as a leading manufacturer of underwater lights for deep diving submersibles, offshore oil and commercial divers. Thru-Hull SeaLites® - whiter, brighter and more durable.
|
|
|
|
|
|
|
For decades DeepSea Power & Light has been designing innovative underwater products that exceed industry standards. The MiniLED Thru-Hull SeaLite® was engineered to fill a need for a powerful, rugged light, in a compact package.
Utilizing the latest in high brightness LED technology, the MiniLED Thru-Hull SeaLite® provides incredible light output for its size. The MiniLED Thru-Hull SeaLite® is ideal for center console boats, where space is at a premium, and price is an important consideration. All electronics are integrated in the watertight housing, providing protection and simplifying installation. Simply run the power cable from the back of the light to your power source – there is no driver box to mount or interconnect cable to route. The MiniLED Thru-Hull SeaLite® is even serviceable from inside the boat. With an ultra long life, the MiniLED Thru-Hull SeaLite® requires no bulb maintenance!
The MiniLED Thru-Hull SeaLite® provides the peace of mind in knowing that it was designed by a company with over 20 years expertise as a leading manufacturer of underwater lights for deep diving submersibles, offshore oil and commercial divers. Thru-Hull SeaLites® - whiter, brighter and more durable.
|
|
UNDER HULL SPOT LIGHT
Codice prodotto: EPFB0001
The thinnest and most powerful under hull spot light ever made. The LED lights with which it is made of give out the brightness correspondent to an alogen lamp of more than 100 Watt. Minimum dimensions, extremely low consumption, with a fixing hole to be made of less than 2 cm.
|
|
The Sea Vision SV14 weld in model for aluminum hulls can be installed in the transom or the hull, it utilizes a 150 watt metal halide lamp and 110 or 230 volt AC power. The lights can be welded at adjustable angles to suit all hull shapes. The hull shape and positioning will dictate the angle of the light you require, angles available are 0-50 degree. All angle options are available on request.
|
|
The UL Ti MATE 75 SA 'Super Adjustable' (patent pending) weldin from Underwater Lights LIMITED ™ for aluminum and steel hulls can be installed in the transom or the hull. The SA reflector unit allows a change in beam direction of up to 20 degrees. This is available with either a 150 or 250 watt metal halide lamp with a 110-230 volt ELECTRONIC ballast, perfect for DC power on a yacht with either and aluminium or steel hull. A 30 and 50 degree angle is also available in both materials.
S00330 - 75 - SA - UL Ti MATE 75 SA 30 Degree Stainless Steel
S00350 - 75 - SA - UL Ti MATE 75 SA 50 Degree Stainless Steel
S00630 - 75 - SA - UL Ti MATE 75 SA 30 Degree 5083 Aluminium
S00650 - 75 - SA - UL Ti MATE 75 SA 50 Degree 5083 Aluminium
|
|
The Sea Vision SV10 model offers the largest aperture of all the fiberglass models giving maximum light output from the 150 watt metal halide lamp. It can be installed in the transom or the hull and is suitable for boats with 110-230 volt AC power, including sportfish, yachts and cruisers.
|
|
The UL Ti MATE 475 'SA' Super Adjustable (S00475) (patent pending) from Underwater Lights LIMITED ™ houses the new Super Adjustable unit which allows a change in beam direction of up to 20 degrees. This is available with either a 150 or 250 watt metal halide lamp with a 110-230 volt ELECTRONIC ballast, perfect for AC power on GRP/Fibre Glass hulls
|
|
The Sea Vision SV14 weld in model for steel hulls can be installed in the transom or the hull, it utilizes a 150 watt metal halide lamp and 110 or 230 volt AC power. The lights can be welded at adjustable angles to suit all hull shapes. The hull shape and positioning will dictate the angle of the light you require, angles available are 0-50 degree. All angle options are available on request.
|
|
The UL Ti MATE 75 SA 'Super Adjustable' (patent pending) weldin from Underwater Lights LIMITED ™ for aluminum and steel hulls can be installed in the transom or the hull. The SA reflector unit allows a change in beam direction of up to 20 degrees. This is available with either a 150 or 250 watt metal halide lamp with a 110-230 volt ELECTRONIC ballast, perfect for DC power on a yacht with either and aluminium or steel hull. A 30 and 50 degree angle is also available in both materials.
S00330 - 75 - SA - UL Ti MATE 75 SA 30 Degree Stainless Steel
S00350 - 75 - SA - UL Ti MATE 75 SA 50 Degree Stainless Steel
S00630 - 75 - SA - UL Ti MATE 75 SA 30 Degree 5083 Aluminium
S00650 - 75 - SA - UL Ti MATE 75 SA 50 Degree 5083 Aluminium
|
|
- Polished or Chrome Plated Bronze with Mounting Ring
- Two Bulb Options
25° Beam Bulb (3000 CB Candle Power)
40° Beam Bulb (1700 CB Candle Power)
- 10 Feet of 16/2 Electrical Cable
- Safety Seal Design Prevents Water Intrusion in the Event of Glass Breakage
- Terminal for Bonding Wire
- DP Includes Green & Blue Lens Filters
|
|
The Sea Vision SV20 model is our standard xenon light with a 35 watt xenon lamp and 12 or 24 volt ballast. This light is suitable for small boats wanting to utilize 12 or 24 volt DC power and can be installed on sport fishers, center consoles, cruisers and performance boats.
|
|
The Sea Vision SV16 model utilizes a halogen lamp with 12 or 24 volt DC power and can be installed in the transom or the hull. Generally it should be installed in smaller boats and for the occasional light user.
|
|
Brand new lighting technology has allowed us to introduce the Sea Vision SV19 model. This utilizes a 50 watt xenon lamp and 50 watt ballast. This is the first of its kind to incorporate the ballast and ignitor built directly into the thru-hull casing. It is the brightest 12 volt DC light available. Can be installed on small to mid size boats including sportfishers and cruisers.
|
|
The Sea Vision SV14 weld in model for aluminum hulls can be installed in the transom or the hull, it utilizes a 150 watt metal halide lamp and 110 or 230 volt AC power. The lights can be welded at adjustable angles to suit all hull shapes. The hull shape and positioning will dictate the angle of the light you require, angles available are 0-50 degree. All angle options are available on request.
|
|
The Sea Vision SV10 model offers the largest aperture of all the fiberglass models giving maximum light output from the 150 watt metal halide lamp. It can be installed in the transom or the hull and is suitable for boats with 110-230 volt AC power, including sportfish, yachts and cruisers.
|
|
The Sea Vision SV10 model offers the largest aperture of all the fiberglass models giving maximum light output from the 150 watt metal halide lamp. It can be installed in the transom or the hull and is suitable for boats with 110-230 volt AC power, including sportfish, yachts and cruisers.
|
|
|
Underwater floodlights complete Yachtlite's extensive product palette for yachts. Yachtlite provides highest quality underwater floodlights with certification from a long-standing reputable manufacturer.
|
|
|
The UL Ti MATE 80 - 100 watt halogen (S02555) by Underwater Lights LIMITED ™ uses a 100 watt halogen lamp with 12 or 24 volt DC power.
|
|
|
The UL Ti MATE 80 20 watt LED is available in 12 or 24 volt.
|
|
Description:
- Polished or Chrome Plated Bronze with Mounting Ring
- 10 Feet of 16/2 Electrical Cable
- Safety Seal Design Prevents Water Intrusion in the Event of Glass Breakage
- Terminal for Bonding Wire
- L.E.D.'s Provide Longer Life, Less Heat and 1/10th the Energy of Standard Lights
|
|
|
|
