The ANNAEVA push buttons type have been designed for the control of low voltage small loads such as relays, interfaces, dimmers, etc. via normally opened push buttons with momentary action.
The push buttons, depending on the model, have from 1 to 6 push buttons.
DOME TECHNOLOGY
FOR INTERIORS
VERY LOW RECESS
Protection grade IP 20
Material Stainless Steel
Spring Installation
|
|
|
|
|
|
|
NERO is a capacitive touch switch button which relaces the standard switch and push buttons for the switching on/off function and for the control of audio/video devices but with a step ahead. Unlike the standard switch buttons, as you don't need to make holes for it, it can be used in the most unusual modes and places thus allowing to give to the boat an unique style. Its very small dimensions enable space saving and give full to the interior designers.
NERO can be set as switch or push button and is available in several models, from one up six switches, it can disappear behind whatever surface or can be provided with a frame of different colours, versions and materials. It is also being properly designed in order to fit perfectly inside plates and material of the main electric productors suppliers.
Among the new models very interesting are NERO DIMMER an electronic light control provided with dimmer device at a low voltage and NERO DIMMER LED the electronic dimmer at low consumption for power led.
|
|
Elby is the wireless push button battery and maintenance free.
It can be installed everywhere for several functions for the expansion of the lighting system, buzzer installation and others without masonry works and saving time.
|
|
2-pole Selector switch 0-1-2-3 12-24Vdc 150mA maxi.
60x60mm Navylec range, varnished printed circuit.
|
|
- For use with 6, 12, 24 and 32 Volt Marine Electrical Systems
- Capacity - Rated 380 AMPS Continuous, 850 AMPS Intermittent (5 Minutes On, 5 Minutes Off)
|
|
|
Panel for 2 Battery Key Switch + 1 parallel Key Switch 200A (Max 1500A)
|
|
Single-pole, triple-throw switch permits four connection modes: Battery One, Battery Two, two batteries in parallel, or both off. Rated for 230 amps continuous, 345 amps momentary. For 6-volt to 32-volt systems. Includes alternator field circuit disconnect to prevent surges. Selector has positive click positions. Bakelite housing with copper washers, brass terminals, and brass nuts. Install with #10 screws.
|
|
New in 2006 the panel mount range of battery switches are designed specifically for panel mount applications. This range gives a very compact, versatile solution with the following features:
Features:
- Fits standard BEP battery switch label range.
- Removable key
- CSK recessed for surface mount application
- Standard 2 1/16" hole cut out (Same as standard gauge hole)
- Ignition Protected
- Full access for cables with no restrictions
- Fit into Contour Connect Panel
|
|
MAIN SWITCH AND MAIN FUSE UNIT WITH CHARGE RELAY
Compact main switch unit, flush mounting
Corrosion-resistant structure.
|
|
|
Copper contacts, stainless steel springs; polycarbonate body; fitted with automatic power interruption on the alternator if the battery isolator activates before turning off the engines. Specially suited for diesel motorizations, which due to large starting motors require heavy amperage; EC DIP 03299 certification made in accordance with law 94/95.
|
|
|
Sea-Fire engine interrupt systems will automatically shutdown engines and powered ventilation upon a discharge of the fire extinguishing system
|
|
|
Panel for 4 waterproof switches or push buttons + black rubber cover nut for waterproofing rearming thermal fuse.
|
|
|
The main innovation of the multipurpose HRC hand-held remote control is the built-in LED lamp, facilitating operation in the dark. This is the only hand-held remote in the nautical sector with this exclusive feature.
|
|
Compact main switch and fuse unit with cover and
charge relay, flush mounting.
Equipped with lock.
Corrosion-resistant robust structure.
|
|
|
The yacht of your dreams is a personal choice, fitted with the finest materials and equipment available. Nothing should be left to chance, least of all your electrical system. If you want the convenience of an electrical panel controlling all functions on board, a MasterVision modular electrical switchboard is the ideal solution. With over 250 different modules and components to choose from, assembling a tailor made electrical switchboard could not be easier: ask the shipyard/installer or do it yourself.
|
|
Panel L w/1 double-pole power selector switch -3 pos 63A 1-2-3 230V AC.
|
|
FLOATING TRANSMITTER
In case of fall into the water, the transmitter will fl oat allowing an easy
and prompt salvage.
|
|
|
|
|
|
|
The installation of a radio remote control system does not imply any modification of the existing control station.
Thanks to this transmitter, extremely easy in handle, equipped with commands buttons well protected against unintended manoeuvres, you will be able to manage the ship by your self, evaluating at best the space at disposal.
NAVIGATION IN NARROW PASSAGES
The harbour and the channels navigation, are some of the most delicate phase for the skippers. The radio remote control IMET will allow you to manoeuvre the boat by yourself, from the most suitable position. A traditional stationary control console does not give the same degree of accuracy and efficiency.
MOORING
IMET radio remote control allows you to moor by yourself in absolute safety conditions, from any place of the boat, controlling the Right and Left engines, the bow and stern propeller. Choosing the most suitable point of view, you will approach comfortably the harbour’s wharf.
TO BITT THE ROPES
Keeping the complete control of your boat at your fingers, you can approach the wharf and recover the ropes with extreme simplicity,
adjusting the trajectory from you transmitter with small engine corrections. This high control capacity will also reduce the possibility of small collisions.
ANCHORAGE
Standing at the bow, you will be able to raise or drop the anchor, keeping an eye at the safe anchorage and at the presence of other anchors.
|
|
SAFETY KEY
This extractable “contact less” key allows the use of the radio remote to
authorised personnel only. The key extraction stops any operation.
|
|
The Smartswitch BC-8000 Controller provides an intelligent networked solution for the monitoring and control of up to eight bilge areas. When any bilge area runs for more than one minute an alarm sounds. If the high float detects water the alarm will sound. You can controll the pump by switch the system into manual mode. The system is happy with pumps up to 40 AMPS. Want to know how many times the bilge area pupm was activated? Easy with the BC-8000 from Smartswitch
The system consists of the BC-8000 display controller (as seen above) up to eight BC-100 or BC-100/P controllers and one (optional) RB-800 repeater displays. The system communicates via a 2-wire network cable with a maximum cable length of 1000 meters
|
|
The Smartswitch NavLight monitor (NV-8000)will monitor and control all the Navlights and alarm when there is a fsulty or blown light. Navlights can be put into 6 programmable groups, twilight sensor option, all lights are name programmable,
Also available is the (NV-2000) will monitor up to 32 lights.
|
|
