New NaviLED Trio - High technology for high places
Hella marine introduces the worlds most advanced LED Tri-Colour.
Designed and manufactured in New Zealand, the new state of the art LED navigation lamp provides class leading energy efficiency, reliability and safety.
With an ultra low current draw of <3.5W for Port, Starboard and Stern combined and <1.5W for the anchor function, the power saving benefits are substantial compared to the 25W consumed by incandescent Tri-Colour lamps.
Sophisticated Hella marine Multivolt electronics ensure consistent and safe illumination plus lamp protection under severe voltage fluctuations, low battery voltages and across long cable runs.
The complete light unit mounts on a secure 316 stainless steel shaft via a pre-wired plug and socket for a reliable electrical connection and ultra secure installation. The unique system also allows for a swift and easy removal and re-installation. Lightweight, completely sealed device, impervious to saltwater and contaminants for an ultra long life and reliability at sea.
Advanced Hella marine lens and optics technology ensures visibility and safety at sea with ultra precise horizontal and vertical cut-off angles compared to incandescent lamps, clearly indicating a vessel’s movement and heading. The NaviLED Trio lamp is internationally certified according to BSH, IMO COLREG, USCG and ABYC.
With class leading efficiency, reliability and a user-friendly installation system, the Hella marine NaviLED Trio provides comprehensive features and benefits backed by a 7 year factory warranty.
|
|
These navigation lights belong to the newest generation of lights. They are protected by many patents and characterized by the most intensive light luminosity, clarity of colours, high resolution lenses, innovative patented design and vanguard electronics. It is undoubtedly the best product available in the market in this category. The lights are certified as compliant with the strictest requirements of IMO COLREG 1972 Regulation.
EPLF0010 - GREEN 112.55%u02DA LED Starboard (right) Navigation Light for Boats of %u2264 20 m
EPLF0015 - RED 112.55%u02DA LED Port (left) Navigation Light for Boats of %u2264 20 m
Technical Characteristics
Field of application: boats < 20m
Visibility arc: 112.5°
Input voltage: 9-30Vcc
Luminous source: power red or green LED 1W
Protected against polarity inversion and spike
Equipped with supply cable
Maximum absorbed power: 2W
Impact resistant
Mechanical protection standard: IP56
Average life of the LED: 10.000 hours
Easy to install
|
|
Deck Floodlight and Masthead Lamp combined in one robust housing.
Suitable for vessels up to 20m in length.
Features:
- Masthead lamp 2LT 002 984-30
- Hella 'Free Form' reflector technology
- Flexible mounting arms for mounting on a variety of mast profiles
- Illuminates large areas of deck or superstructure
- Glass lens bonded with reflector to be dust and moisture resistant
- Covered bulbs for moisture protection
- All metal parts are stainless steel
- Black or White fibre reinforced housing
|
|
Compact LED navigation lamps. Pre wired and completely waterproof.
- 2 Nautical Mile Visibility
- Long service life
- Impact and vibration proof
- Low power consumption
- Multivolt 8-28V DC
- Approved by: IMO COLREG, USCG, RINA (I), ABYC A-16, NMSC
Available in either Black or White Shrouds, with clear or coloured lens.
|
|
BSH approved LED navigation lights.
Designed and manufactured in New Zealand, NaviLED PRO lamps are a quantum leap forward in energy efficiency and durability.
Combining the latest LED and Multivolt 9-33V DC technology, the NaviLED PRO range have ultra low power consumption, just 10% of that required to run a bulb navigation lamp, just 3.2 watts.
Fully sealed in UV and high impact resistant acrylic, and pre-wired with 2.5m of marine cable, these lamps are IP67 certified making them extremely reliable.
Available in either Black or White shrouds.
|
|
These navigation lights belong to the newest generation of lights. They are protected by many patents and characterized by the most intensive light luminosity, clarity of colours, high resolution lenses, innovative patented design and vanguard electronics. It is undoubtedly the best product available in the market in this category. The lights are certified as compliant with the strictest requirements of IMO COLREG 1972 Regulation.
Technical Characteristics:
Field of application: boats < 20m
Visibility arc: 360°
Input voltage: 9-30Vcc
Luminous source: power white LED 2.5 W
Protected against polarity inversion and spike
Equipped with supply cable
Maximum absorbed power: 3.5W
Impact resistant
Mechanical protection standard: IP56
Average life of the LED: 10.000 hours
Easy to install
|
|
Designed and manufactured in New Zealand, NaviLED®360 lamps draw a fraction of the energy required to run a conventional 2 nautical mile bulb lamp. Hella marine LED technology has no filaments to break thus making the lamps extremely shock, vibration and impact resistant. They are completely maintenance free. High impact acrylic housings provide superior durability in demanding conditions.
NaviLED®360 anchor lamps have undergone extensive 'tested to destruction' programs to help lift product reliability to a new standard. Each lamp is a completely sealed and waterproof unit, UV and corrosion resistant
|
|
• Black Plastic
• Pre-Wired Double Contact Socket and 3 Feet of 16/3-SO Cable
• Watertight Access Cap for Rebulbing and Cleaning
|
|
aqua signal 25 STANDARD – robust navigation light of special plastic in black or white
Voltage:
12 V, 24 V
Housing:
Polycarbonate, shock resistant, non-corrosive, non-magnetic, seawater resistant
Protection:
IP 45
Optics:
(Fresnel) plastic
Electric:
2/3 pol.
Range of visibility:
1 nm, 2 nm. (starboard, port, bicolor)
Application vessels:
< 12 m / 39’ (Scandinavia < 7 m / 23’)
Authorisation:
CE, USCG, IMO
|
|
Modern design and optimized size for sport boats and yachts up to 50 m length. 2 LEDs for more color-brightness and double safety. Power consumption. Vibration resistant. Easy installation with waterproofed plug-in connection.
Voltage:
12 – 24 V DC, +/- 20%
Housing:
Polycarbonat in black or white. UV- and saltwater resistant
|
|
Series 32 LED - navigation lights, application vessels < 50 m / 163’, visibility 2 nm / 3 nm, housing and optics non-corrosive, seawater resistant, consumption extremely low
Voltage:
12 V, 24 V
Housing:
Polycarbonate in black or white, shock resistant, non - corrosive, non – magnetic, seawater resistant. The LED-body is thermally connected to a machined aluminium casing which keeps it cool allowing a liftetime of more than 50.000 hours. Optional stainless steel covers available for port-, starbord-, stern- and bicolor lights
Optics:
Patented optics are UV- and saltwater resistant requiring only a single LED per light source
Electric:
Low power consumption (1,5 W per sector). Current from 12 – 24 V. Invers polarity protection
Authorisation:
CE, BSH, USCG, RINA, IMO
|
|
- Standard Flash Pattern - 14, 24, 30, 60 FPM (flashes per minute)
- High-intensity LEDS (no bulbs)
- Efficient solid-state circuitry
- One year warranty
- High impact resistant
- UV stabilizer
- Clear lens
- Water tight
- Replaceable backup batteries last up to 5 years
|
|
aqua signal 40 - traditional and robust navigation light of stainless steel and special plastic. Application vessels < 20 m / 65’
Voltage:
12 V / 24 V
Housing:
Polycarbonate black or white. shock resistant, non-corrosive (stainless steel), non – magnetic, seawater resistant
Optics:
(Fresnel) plastic, seawater resistant
Protection:
IP56/IP55
Electric:
2 pol.
Cable entry:
PG 9
Visibility:
2 nm, 2 nm (flash 3 nm), 3 nm, Topp 3 nm, anchor 2 nm
Authorisation:
CE, BSH, USCG, IMO
|
|
• Cast Bronze, Plain or Chrome Plated
• Complete with Double Contact Electrical Socket
|
|
|
AISI 316 stainless steel base with self-locking adjustment at various heights, fully made of stainless steel, serves as flag-holder as well as stern light.
|
|
Sidelights are forward-facing colored lights, green on the starboard side and red on the port side. Navigation lighting requirements vary depending on the size of your boat.
|
|
Features a krypton bulb that burns bright and lasts long. Constructed of rugged high-impact resin. Easy thumb switch operation.
|
|
|
Made of white polycarbonate with plexiglass lens; made in accordance with IMCO and R.I.Na standards for motor boats up to 12 metres.
|
|
Forespar® now offers two mast light systems of superior quality. Model ML-1 is a deck light designed primarily for installation on the mast just below the spreaders. Model ML-2 is a combination deck-bow light with separate switching, to be mounted on the forward part of the mast.
ML-1 & ML-2 lights feature a durable molded polymer housing assembly with a readily adaptable wraparound mounting apron to accommodate virtually any mast surface curvature. For 12V systems. Replacement bulbs are available from Forespar® and most marine dealers.
|
|
Visibility Lights signal your watercraft's position and direction and status to other watercrafts helping to avoid collisions.
Mount the red light on the left or port side and the green light on the right or starboard side. If an approaching watercraft sees the green light, he has the right of way. If the approaching watercraft sees the red light, your watercraft has the right away.
Features:
- Each strip contains 6 ultra-bright LEDs
- All cables and assembly insruction included
- Weather and wake resistant
- LED bulb life is approximately 100,000 hours
- Equipped with double insulated wiring
- Low current draw, 50-70 mA's per light
|
|
|
|
|
|
|
- Contemporary Styling
- Plastic Top
- 12 Volt Bulb
- 3/4" Diameter Anodized Tube
- Fold in Half Pole
- Wide 40 Head Adjustability (+-20°)
- 2 Screws Positions for Multiple Base Applications
- 2 Globes Included
- Large Threaded Collar
- Locking Collar
The new Delta Series is the Ultimate Replacement Pole Light. The series offers the features of virtually every other replacement pole light on the market all in one single package.
Universal Type - DP Package includes two globes. A reduced glare globe preserves night vision while under way. A fully clear globe functions as a traditional globe offering cockpit illumination while still metting navigation light requiremments. No tools are required. Globes simply screw on and off.
Universal Fit - DP Packages light includes two collars and provides two key slot screw positions so that the Delta series fits more popular bases than any other light on the market.
Universal Angle - The big 40 degree (+-20°) tilt range of the Delta series can be easily and widely adjusted. This allows Delta series lights to match all other popular base angles. In addition, the Delta series lights can be adjusted even further to match most custom bent pole applications supplied as original equipment on many boats.
|
|
- Divide your consumption by 10 !
- Very high efficiency LED lamp
- Very long life: >50,000h (estimate)
- Nominal supply voltage: 12 to 24VDC
- No Polarity: can be connected without regard to polarity
- Power consumption: 1W typ.
- Current draw: <90mA @ 12VDC / <45mA @ 24VDC
- With electronic regulation
- Supply voltage range: 9 to 30VDC max.
- Negligible heating
- Operating temperature: -30 to +80°C
- View angle: 300° horizontal / 120° vertical
- Dimensions: Ø 0.79"
- Available in lengths: 1.42" / 1.5" / 1.62"
- Pictures and information may be changed or updated without notice
|
|
- Divide your consumption by 20 !
- Very high efficiency LED lamp
- Very long life: >50,000h @ 25°C (estimate)
- Nominal supply voltage: 12 to 24VDC
- No Polarity: can be connected without regard to polarity
- Very low power consumption: 1.8W typ.
- Current draw: <150mA @ 12VDC / <80mA @ 24VDC
- With electronic regulation
- Supply voltage range: 9 to 30VDC max.
- Negligible heating
- Operating temperature: -30 to +80°C
- View angle: 360° horizontal / 120° vertical
- Dimensions: Ø 1" x 2.3"
- Available with BA-15S or BA-15D or BAY-15D bayonet base
|
|
