The WillDo MINI Jet Thruster, available in a 20 or 30 kgf version, is an entirely new and ingenious development by WillDo. It is a so-called two-way system which does not have a seperate inlet like the other models, but only two small openings. Simultaneously, one of the openings functions as the suction end and the other opening as the pressure end, where the thrust force is generated and, of course vice versa when you need to manoeuvre into the opposite direction. This procedure is made possible by the specially designed WillDo floating nozzles, to provide enough water supply. The bidirectional electric motor drives the vane pump which has been especially developed by us.
|
|
The Willdo Jet Thrusters are driven hydraulically (not electrically) by the propulsion engine. A hydraulic pump, which is fitted onto the propulsion engine, drives an hydraulic motor, located in the pump housing, which in turn activates a water pump, that sucks in the water through an opening in the bottom of the boat and presses it wih great force, via hoses with an inside diameter of no more than 45mm, to the nozzles in the sides of the boat.
Each WillDo electrically driven Jet Thruster consists of a unidirectional DC motor (standard equipped with a thermal protector!), driving a centrifugal impeller. As this impeller is immersed in water it starts to prime the surface water and build up the pressure. The water flows through the flexible hoses via the diverter valves to the outlet openings, which have a diameter of ø32mm (up to 50kgf) or ø46 for the bigger units. These openings must be positioned into either bow or stern (Single) or in both (Combi). The water intake (available in stainless steel 316 or aluminium) has a diameter of 90mm and is equipped with a grid to prevent larger objects from getting into the system. Smaller debris that floats in the water and can pass through the grid, will not cause any damage to pump and valve.
|
|
EXTURN 130
external bow / stern thruster 1,3 kW, 12V
recommended boat size : 7 - 9 m (23 - 30 ft.)
|
|
EXTURN 230
external bow / stern thruster 2,3 kW, 24V
recommended boat size : 10 - 13 m (33 - 43 ft.)
|
|
EXTURN 300
external bow / stern thruster 3,0 kW, 24V
recommended boat size : 12 - 15 m (39 - 49 ft.)
|
|
IN-LINE THRUSTER Model 16SHT
The Model 16SHT thruster is designed for vessels from 90-112ft (27-34m) in length. The custom-engineered highly skewed stainless steel propeller and sleek thruster assembly provides extremely quiet operation. High grade Stainless Steel used throughout the assembly results in long, reliable marine service life.
|
|
IN-LINE THRUSTER Model 8HT
The Model 8HT thruster is designed for vessels from 38-48ft (12-15m) in length. The custom-engineered highly skewed stainless steel propeller and sleek thruster assembly provides extremely quiet operation. High grade Stainless Steel used throughout the assembly results in long, reliable marine service life.
|
|
IN-LINE THRUSTER Model 20LHT
The Model 20LHT thruster is designed for vessels from 136-166ft (41-52m) in length. The custom-engineered highly skewed stainless steel propeller and sleek thruster assembly provides extremely quiet operation. High grade Stainless Steel used throughout the assembly results in long, reliable marine service life.
|
|
|
The commercial pedigree of NAIAD Right Angle Thrusters provides a robust, high strength thruster resulting in years of trouble-free performance. The Model 12 is typically specified for vessels from 40-80ft (12-25m) in length. Available in aluminum for aluminum hulls, and in stainless steel for all other hull materials. Easily configured for either hydraulic or AC electric drive to suit the needs of any application.
|
|
|
The commercial pedigree of NAIAD Right Angle Thrusters provides a robust, high strength thruster resulting in years of trouble-free performance. The Model 24 is typically specified for vessels from 100-150ft (30-46m) in length. Available in aluminum for aluminum hulls, and in stainless steel for all other hull materials. Easily configured for either hydraulic or AC electric drive to suit the needs of any application.
|
|
EXTURN 180
external bow / stern thruster 1,8 kW, 12V
recommended boat size : 8 - 11 m (26 - 36 ft.)
|
|
|
A propeller transforms engine power into thrust, which in turn, overcomes the boat’s resistance and move it in the required direction, fully in accordance with the laws of nature. But now, when we introduce a complete range of the patented swing bow and stern thruster designed and developed in Sweden – the Swing Thruster – it’s time to think again. With the RMC Swing Thruster, you get 30-50% greater efficiency, low sound level and minimal cavitation. And last but not least, it does not require a tunnel through the hull, which reduces boat speed.
|
|
|
Installed in combination with a bow thruster the stern thruster improves boat manoeuvrability and greatly simplifies berthing, even with larger boats. QL stern thrusters are recommended for boats with inboard engines, (single installation) with a conventional propeller shaft. They are installed at the stern, with the motor inside the hull and the propeller tunnel outside the transom. The tunnel has a flared inlet and outlet in order to improve flow.
|
|
The stern thrust installation, developed and produced by ALMAR, is being mounted underneath the bathing plattform at least 80 mm below the water-line on the outside onto the flat of the stern. The mounting is very easy as only a drilling on the hull of 60 mm in diameter is necessary in order to guarantee the power supply. For mounting, 4 screws are provided on both ends. In the driving range the aggregate itself is encapsulated completely waterproof. The complete unit is plastic-laminated and after the installation coated with antifouling. The propeller shaft is sealed twice by special shaft seals. Caused by the special construction of the water in- and outlet area a high efficiency is achieved.
- easy mounting is possible at any spot of the ship's rear,no disturbingparts at the inside of the ship
- only space necessary for cable installation
- perfect for after cabin
|
|
Installing an electric bow or stern thruster in a petrol (gasoline) engined boat can be very dangerous, due to the possibility of the electric motor igniting fuel vapour.
In order to eliminate the risk, this special housing will shield the bow or stern thruster from potentially explosive vapour. The housing enables the thruster to comply with the ISO 8846 Marine "ignition protection" standard. In addition to the standard thruster, the set consists of a watertight (IP65) housing for the electric motor and relays, together with all required seals, electrical connectors and fastening components. An automatic fuse for the control loom is also supplied. This can be reset externally without opening the housing.
|
|
DETAILS
The ST 340 is made specifically for boating vessels up to 40 feet in length.
- 24" Wide X 10" Long
- 12 Volt DC, 550 Amps, Dual Prop
ALSO INCLUDED
- Harness that runs from the thruster to the motor controller.
- Mounting hardware.
- Compression terminals.
- Joy stick (dual joystick available for both bow and stern).
- Installation manual.
- Computerized test results.
|
|
DETAILS
The ST 350 is made specifically for boating vessels up to 50 feet in length.
- 24" Wide X 10" Long
- 24 Volt DC, 400 Amps, Dual Prop
ALSO INCLUDED
- Harness that runs from the thruster to the motor controller.
- Mounting hardware.
- Compression terminals.
- Joy stick (dual joystick available for both bow and stern).
- Installation manual.
- Computerized test results.
|
|
DETAILS
The ST 380 is made specifically for boating vessels up to 80 feet in length.
- 25" Wide X 10" Long
- 24 Volt DC, 750 Amps, 4 Props
ALSO INCLUDED
- Harness that runs from the thruster to the motor controller.
- Mounting hardware.
- Compression terminals.
- Joy stick (dual joystick available for both bow and stern).
- Installation manual.
- Computerized test results.
|
|
28 Models, hydraulic and electric double thrust counter rotating and single prop systems for pleasure boat and commercial applications, from 5 to 350 horsepower.
Tested for power, prop size and pitch, clearance and configuration up to 15 hp in WESMAR's one-of-a-kind world-class testing lab
|
|
|
|
