The ED35A ceiling system consists of a sheet metal half-tray filled with mineral wool. This design features low weight and a solid and stabilizing substructure. The prefabricated border profiles of the wall system provide additional strength without the need for top profiles. In larger rooms, the panels can be installed with center profiles. After the substructure is mounted, the panels are laid into it and screwed on using retention hooks. With the exception of the two screws needed to attach the final panel, no screwed connections are visible.
|
|
The SD35A ceiling system is a sandwich construction made of sheet metal and mineral wool. This design features a high load-bearing capacity. The prefabricated border profiles provide additional strength to the wall system without the need for top profiles. The ceiling can be installed without consideration of the wall height.
After the substructure is mounted, the panels are screwed onto the ceiling using retention hooks. Assembly can be completed from the lower side of a specially designed final panel. With the exception of the two screws needed to attached the final panel, no screwed connections are visible.
|
|
|
Aesthetic, fireproof and light, Lautex ceilings are especially suitable for the shipbuilding industry. The most common materials used in the construction of Lautex ceilings are aluminium and steel. Lautex suspended ceilings are certified in fire resistance classes C, B-0 and B-15, thus meeting the requirements of the official authorities. All our products have passed the flue gas and non-toxicity-tests.
|
|
Technical data
Weight incl. joint profiles
11,5 kg/m2, width 300 mm
Weight incl. joint profiles
10,2 kg/m2, width 500 mm
Panel thickness
15/50 mm
Panel width standard
300, 500 mm
Panel length max.
3000 mm
|
|
Technical data
Weight incl. joint profiles
20,0 kg/m2
Panel thickness
50 mm
Panel width min.
175 mm
Panel width max.
600 mm
Panel length max.
3000 mm
|
|
|
|
|
|
|
PANEL CEILING B0 and B15
A panel ceiling is designed to be used on vessels and in industrial land projects. Various classes of fire protection are met thanks to insulation from non-combustible mineral wool. An even / smooth / surface and an easy assembly are main advantages of this type of construction.
Construction
The ceiling consists of lining elements, girders and suspending elements. As lining elements there are used ceiling strips, 300 mm wide, with thermal insulation from non-combustible mineral wool density 110 kg/m3 . Lengtwise edges are shaped in such a way that they form their own "feathers" thanks to which panels are connected smoothly. A connector put into an edge of a strips makes this construction rigid / it's also a mounting element of a supporting structure /. Mounting girders together with ceiling profiles form a supporting structure. The supporting structure is hung up to the deck / or ceiling / with suspension metal elements which eneble to make an easy connection with girders and flexible levelling of ceiling higher class of fire protection is obtained by putting an additional layer of mineral wool as panels and girders.
|
|
|
Today, Dobel is found on ships sailing the world’s seas. We are a world-leading laminated sheet steel supplier in the marine sector. This is something we say with great pride, particularly considering the stringent demands the marine sector places on its suppliers.
|
|
|
|
|
|
|
Jamestown can supply joiner bulkhead systems for any application including softcore, hardcore and sheathing.
Softcore %u2013 The STACO panel system provides the combination of economical installation together with the qualities of both sound reduction and fire rating. These panels are a sandwich configuration having a steel (or aluminum) skin and a mineral wool core. This system meets all the applicable classification and regulations including SOLAS and US Coast Guard. There are over 10,000 surface patterns to choose from and limitless colors.
Hardcore %u2013 Jamestown can supply solid core joiner panels having a finished surface of high pressure plastic laminate, veneers or other special applications. These panels meet all the applicable classification and regulations including SOLAS and US Coast Guard.
Sheathing %u2013 Metal sheathing, including stainless steel, can be supplied where ease of cleaning is needed in areas such as galleys and storerooms.
Specialty %u2013 Honeycomb material construction bulkhead systems are available for application in areas requiring lightweight such as high speed craft, yachts and naval vessels.
|
|
|
Today, Dobel is found on ships sailing the world’s seas. We are a world-leading laminated sheet steel supplier in the marine sector. This is something we say with great pride, particularly considering the stringent demands the marine sector places on its suppliers.
|
|
|
Today, Dobel is found on ships sailing the world’s seas. We are a world-leading laminated sheet steel supplier in the marine sector. This is something we say with great pride, particularly considering the stringent demands the marine sector places on its suppliers.
|
|
|
WAS-Celing panel system is for the ceiling of each living space. It is lightweight and is enhanced to offer fire and noise protection. Because of the innovative design, this wall panel has received many certifications.
|
|
|
WAS-Celing panel system is for the ceiling of each living space. It is lightweight and is enhanced to offer fire and noise protection. Because of the innovative design, this wall panel has received many certifications.
|
|
|
The lightweight WAS ceiling system combines rigidity and strength, and is designed for both traditional and modular construction.
|
|
|
The lightweight WAS ceiling system combines rigidity and strength, and is designed for both traditional and modular construction.
|
|
|
Wall panels exist among living spaces between rooms and between each room and the hallway. They are also used in public spaces (including the kitchen, resting space, hospital, and storage area). By changing to our wall panel system, protection from light and noise and potential fire has been made more effective. Because of this, our panels have already been authenticated by and received numerous certifications from international organizations.
|
|
|
Wall panels exist among living spaces between rooms and between each room and the hallway. They are also used in public spaces (including the kitchen, resting space, hospital, and storage area). By changing to our wall panel system, protection from light and noise and potential fire has been made more effective. Because of this, our panels have already been authenticated by and received numerous certifications from international organizations.
|
|
Constructional system of bulkheads and linings characterizes by almost complete prefabrication of elements and mounting profiles. It ensures easy and fast installation, and accomodations of high standard. Accomodations designed in this system meet the requirements of fire protection of all classes and acoustic insulation.
Apart from basic scope of bulkhead and lining panels we also produce bulkhead and lining panels for wet rooms.
Basic offer
- lining C-25mm
- lining B0/B15-25mm
- bulkhead C-50mm
- bulkhead B15-50mm
- acoustic bulkhead B15-50mm
- bulkhead with cable ducts B15-50mm
- bulkhead B15-80mm
|
|
|
|
|
|
|
Jamestown can supply joiner bulkhead systems for any application including softcore, hardcore and sheathing.
Softcore %u2013 The STACO panel system provides the combination of economical installation together with the qualities of both sound reduction and fire rating. These panels are a sandwich configuration having a steel (or aluminum) skin and a mineral wool core. This system meets all the applicable classification and regulations including SOLAS and US Coast Guard. There are over 10,000 surface patterns to choose from and limitless colors.
Hardcore %u2013 Jamestown can supply solid core joiner panels having a finished surface of high pressure plastic laminate, veneers or other special applications. These panels meet all the applicable classification and regulations including SOLAS and US Coast Guard.
Sheathing %u2013 Metal sheathing, including stainless steel, can be supplied where ease of cleaning is needed in areas such as galleys and storerooms.
Specialty %u2013 Honeycomb material construction bulkhead systems are available for application in areas requiring lightweight such as high speed craft, yachts and naval vessels.
|
|
|
K-600 is designed with integrated joint profiles for rapid installation, leaving a flush surface with single seam joints. Available in standard or modular system.
|
|
|
Wall panels exist among living spaces between rooms and between each room and the hallway. They are also used in public spaces (including the kitchen, resting space, hospital, and storage area). By changing to our wall panel system, protection from light and noise and potential fire has been made more effective. Because of this, our panels have already been authenticated by and received numerous certifications from international organizations.
|
|
|
Wall panels exist among living spaces between rooms and between each room and the hallway. They are also used in public spaces (including the kitchen, resting space, hospital, and storage area). By changing to our wall panel system, protection from light and noise and potential fire has been made more effective. Because of this, our panels have already been authenticated by and received numerous certifications from international organizations.
|
|
|
Wall panels exist among living spaces between rooms and between each room and the hallway. They are also used in public spaces (including the kitchen, resting space, hospital, and storage area). By changing to our wall panel system, protection from light and noise and potential fire has been made more effective. Because of this, our panels have already been authenticated by and received numerous certifications from international organizations.
|
|
|
The WAS bulkhead panels are available as both the sandwich construction panel and the asymmetric shape panel. Modular construction with an insulation core of noncombustible material is between the facing of either laminate or sheet steel clad. We also have special solutions for wet areas such as galleries, laundry rooms, and shower areas.
|
|
|
The WAS bulkhead panels are available as both the sandwich construction panel and the asymmetric shape panel. Modular construction with an insulation core of noncombustible material is between the facing of either laminate or sheet steel clad. We also have special solutions for wet areas such as galleries, laundry rooms, and shower areas.
|
|
|
The WAS bulkhead panels are available as both the sandwich construction panel and the asymmetric shape panel. Modular construction with an insulation core of noncombustible material is between the facing of either laminate or sheet steel clad. We also have special solutions for wet areas such as galleries, laundry rooms, and shower areas.
|
|
|
The WAS bulkhead panels are available as both the sandwich construction panel and the asymmetric shape panel. Modular construction with an insulation core of noncombustible material is between the facing of either laminate or sheet steel clad. We also have special solutions for wet areas such as galleries, laundry rooms, and shower areas.
|
|
