Application
Engine room, refrigerated hold
Protection degree IP56
Hanging ring
|
|
Rugged and low profile luminaire
Tranbergs luminaires are all designed for use in rough environments.
It is the policy of Tranberg to provide products and services that meet the highest standards of quality in the industry and the performance needs and expectations of our customers. The design of Tranberg luminaires is based on many years of experience and extensiveresearch in the field of professional Marine lighting. Carefully selected materials are used to ensure maximum performance, low
maintenance and a long trouble free life.
|
|
|
Tranbergs luminaires are all designed for use in rough environments. It is the policy of Tranberg to provide products and services that meet the highest standards of quality in the industry and the performance needs and expectations of our customers. The design of Tranberg luminaires is based on many years of experience and extensive research in the field of professional Marine lighting. Carefully selected materials are used to ensure maximum performance, low maintenance and a long trouble free life.
|
|
Accommodation area, indoor
|
|
Application : cabins
Approvals : according to the rules of relevant classification societies, additional VDE and IEC
Housing : phosphate coated steel, powder coated white
Diffuser : polycarbonate, opal
Mounting : 4 mounting holes, 3.7 x 6.5 mm, cut out: 187 x 68 mm
|
|
Ideal for berth or mirror lighting.
Opal acrylic diffuser.
Terminal block for incoming wiring.
Multiple knockouts for cable entries.
Direct mounting to bulkhead or deckhead.
Corrosion resistant aluzinc housing.
Epoxy powder coated finish.
|
|
Ideal for berth or desk lighting.
Polycarbonate housing.
Adjustable matt stainless steel reflector.
Terminal block for incoming wiring.
Integral on-off switch.
Direct mounting to bulkhead.
40W incandescent or 7W compact fluorescent.
|
|
Material: - Housing: plastic
- Reflctor: stainless steel
Lamp: Incandescent lamp up to 40W (not included in delivery)
Equipment: 2-pole tumbler switch
|
|
Berth light
Particularly flat and solid for hinged bunks. Only 34 mm thick, resistant material, just ideal for the berth.
Application: Accommodation areas, lounges
Design: According to rules of maritime classification societies, additional VDE and IEC / EN
Protection degree: IP 30
Housing: Aluminium brushed, anodized brown, end caps polycarbonate brown / zinc coated steel sheet, powder coated white, end caps whitel
|
|
Berth light with adjustable reflector
For long time the best lamp for bunks because the beam arrives where it ought to thanks to the reflector being turnable by almost 360°.
Application: Accommodation areas
Design: According to rules of maritime classification societies, additional VDE and IEC / EN
Protection degree: IP 20
Housing: Polycarbonate darkbrown, reflector mat,
stainless steel, deep drawn, interior enamelled
white RAL 9016
Electric: Flexible wiring, silicone insulated, heat
resistant up to 180° C, 1 - way d.p. switch;
connector between wall plate and light
Cable entry: Opening on rear side, dia. 12 x 30 mm
Lamp base: E 14 / B 15 / E 27 or B 22
Light sources (not included): Incandescent all pur-
pose lamp 40W (type 1355) / incandescent tubular
lamp 40 W (type 1354)
Mounting: 2 / 4 mounting holes, dia. 5 mm
|
|
Applications : emergency light, illuminated sign for passage ways, public areas, etc.
Approvals : according to the rules of relevant classification societies, additional VDE and IEC
Housing : zinc coated steel, powder coated white
Sign : PMMA, list of standard pictograms are available, other pictograms on customers requirements
Mounting : 4 mounting holes,Ø 4.5 mmcut out 243 x 60 mm
|
|
Polycarbonate sign.
Corrosion resistant aluzinc or stainless steel housing.
Epoxy powder coated finish.
Terminal block for incoming wiring.
Sign with 2” high red letters as per USCG requirements.
Single or double sided.
Recessed mounted.
8W fluorescent.
Custom signs available.
|
|
Autronica Fire and Security AS has an extensive range of emergency light systems and luminaires intended for small and plain systems to large and complex installations.
Our entire range includes systems and luminaires for many different applications and locations, including different buildings onshore, maritime and offshore applications, weatherproof and vandal resistant applications and many other applications. Our entire range includes systems and luminaires for many different applications and locations, including different buildings onshore, maritime and offshore applications, water proof and vandal resistant applications and many other applications
|
|
Low location lighting
Based on the surface-emitting Optiline fibre optic lighting system, our LLL system allows for stylish and reliable Low Location Lighting. The basic system consists of an aluminium profile with fibre optic light modules mounted to it. High-efficiency and long-lasting LEDS are used as the light source. Installation of the Teknoware LLL system is easy, thanks to its modular construction and ready to fit, waterproof connectors. Aluminium profiles are available in both floor and wall-mountable models. The system is complemented by EXIT signs and end pieces.
The module operating voltage is a safe 6 V DC, and the system power consumption is a very low 20 mA/metre. A waterproof encased 230 V AC/6 V DC power source and battery backup unit are also available for the system.
|
|
Emergency luminaires
Our specially designed ship emergency and exit luminaires provide a reliable and economical solution, without compromising on the style and compatibility of the products. We have advantaged our 30 years of expertise in the manufacture of highly demanding rolling stock and bus lighting solutions to meet the special requirements of shipboard applications.
|
|
Clear prismatic acrylic diffuser.
Terminal block at each end for incoming wiring.
Feed through wiring up to 23A, eliminating the need for field junction boxes.
Multiple knockouts for cable entries.
Adjustable mounting brackets for easy installation in marine ceiling systems.
Corrosion resistant aluzinc housing.
Epoxy powder coated finish.
Spring loaded lampholders that are resistant to shock and vibration.
|
|
Variety of diffusers available for every application.
Terminal block at each end for incoming wiring.
Feed through wiring up to 23A, eliminating the need for field junction boxes.
Multiple knockouts for cable entries.
Adjustable mounting brackets for easy installation in marine ceiling systems.
Ceiling matching profiles included.
Corrosion resistant aluzinc housing.
Epoxy powder coated finish.
Spring loaded lampholders that are resistant to shock and vibration.
|
|
Class 1, Division 2, Groups A,B,C,D, T3B.
Class 1, Zone 2, Groups IIA & IIB, T3B.
Clear polycarbonate diffuser, which is virtually indestructible.
Terminal block at each end for incoming wiring.
Feed through wiring up to 23A, eliminating the need for field junction boxes.
Four cable entries, two in each end.
Corrosion resistant aluzinc or stainless steel deep drawn seamless housing.
Epoxy powder coated finish.
Stainless steel hardware.
|
|
| ... products without information |
| |
- Allround signalling light in different colours for general warning purposes
- Seawater resistant
|
|
Main body of corrosion resistant (seawater) light alloy. Yellow polyurethane paint.
Globe of impact resistant polyamide available in colours red, blue, amber, clear or green.
Approved according to CENELEC EN50014, 50018.
|
|
Luminaire Emergency
Tranberg luminaires are all designed for use in rough environments. It is the policy of Tranberg to provide products and services that meet the highest standards of quality in the industry and the performance needs and expectations of our customers. the design of Tranberg luminaires is based on many years of experience and extensive research in the field of professional Marine lighting. Carefully selected materials are used to ensure maximum performance, low maintenance and a long trouble free life.
|
|
Easy to change safety glass lens.
No tools required for relamping.
Terminal block for incoming wiring.
Corrosion resistant stainless steel deep drawn seamless housing.
Epoxy powder coated finish.
Highly polished aluminum wide beam reflector.
Stainless steel hardware.
|
|
Class 1, Division 2, Groups A,B,C,D, T1.
Class 1, Zone 2, Group II, T1.
Easy to change safety glass lens.
No tools required for relamping.
Terminal block for incoming wiring.
Corrosion resistant stainless steel deep drawn seamless housing.
Epoxy powder coated finish.
|
|
Easy to change safety glass lens.
No tools required for relamping.
Terminal block for incoming wiring.
Corrosion resistant stainless steel deep drawn seamless housing.
Epoxy powder coated finish.
Highly polished aluminum wide or narrow beam reflector.
Stainless steel hardware.
|
|
EEx de IIB T5 Ex II 2 G
For use in Zone : Zone 1, Zone 2
Tranberg luminaires are all designed for use in rough environments.
The helideck light system delivered by Tranberg is designed to meet
the toughest conditions in the helicopter landing areas. The floodlights
are designed to provide adequate illumination of the whole area without
glare to pilots or helicopter personnel in the area. Helideck equipment
manufactured by Tranberg is delivered to offshore installations, oil
tankers and supply ships, hotels and hospitals all over the world.
|
|
|
|
